Nzxt H5 Flow 2024 Edition E-ATX White Mid Tower Case

The NZXT H5 Flow 2024 Edition (model CC-H52FW-01) is a compact mid-tower chassis engineered to prioritise sustained airflow and GPU cooling without sacrificing a clean, minimal aesthetic. Finished in white with ultra-clear tempered glass, it pairs a steel SGCC body with tool-less panel access on the front, side, and top for effortless maintenance. Airflow is central to the H5 Flow's design. Ultra-fine mesh covers the front, top, and side panels, maximising intake volume while filtering dust before it reaches your components. The PSU shroud features perforations on the side and bottom, enabling two 120mm bottom-mounted fans (not included) to draw cool air directly toward the GPU, a layout that meaningfully benefits high-TDP graphics cards. Out of the box the case ships with two F120Q 120mm Quiet Airflow fans (3-pin DC) — one front, one rear — rated at 1,350 ± 150 RPM, 60.2 CFM airflow, 1.05 mm-H₂O static pressure, and 24.1 dBA noise. Additional fans can be fitted at the front (3 × 120mm or 2 × 140mm), top (2 × 120mm or 2 × 140mm), bottom (2 × 120mm), and rear (1 × 120mm) for a maximum of eight fans. For liquid cooling enthusiasts, the H5 Flow supports a 360mm radiator at the front and a 240mm radiator (or 280mm with low-profile memory) at the top. The top-mounted radiator and fan combined thickness is limited to 55mm, so check your AIO dimensions before purchase. Motherboard compatibility spans E-ATX (up to 277mm wide), ATX, Micro-ATX, and Mini-ITX. CPU cooler clearance extends to 170mm, GPU clearance to 410mm, and PSU length to 200mm — accommodating most current high-end components. Cable routing is aided by channels, hooks, and straps offering up to 28.7mm of cable-management space behind the motherboard tray. Front I/O includes one USB 3.2 Gen 1 Type-A port, one USB 3.2 Type-C port, and a headset audio jack. Storage options cover two 2.5" SSD bays and one 3.5" HDD bay. Seven expansion slots are available, with no vertical GPU slot in this configuration. Verified Specifications: – Model: CC-H52FW-01 – Dimensions (H × W × D): 465 × 225 × 430 mm (18.31 × 8.86 × 16.93 in) – Weight: 7.28 kg / 16.04 lb – Motherboard Support: E-ATX (up to 277mm wide), ATX, Micro-ATX, Mini-ITX – Case Material: SGCC Steel + Ultra-Clear Tempered Glass – Pre-Installed Fans: 2 × F120Q (120mm, 3-pin DC, 1,350 ± 150 RPM, 60.2 CFM, 24.1 dBA) – Max Fan Support: 8 – Front Radiator Support: Up to 360mm – Top Radiator Support: Up to 240mm (280mm with low-profile memory) – GPU Clearance: Up to 410mm – CPU Cooler Clearance: Up to 170mm – PSU Clearance: Up to 200mm – Expansion Slots: 7 standard, 0 vertical – Drive Bays: 2 × 2.5", 1 × 3.5" – Warranty: 2 Years
