NZXT H7 Flow E-ATX Mid Tower Case

The NZXT H7 Flow (SKU: CM-H72FB-01) is a mid-tower PC case built around a single focused goal: maximising airflow without inflating the footprint. Its defining feature is a vertical PSU layout that frees up the bottom of the chassis for three additional 120mm fan mounts, giving the GPU a dedicated cooling path that conventional mid-tower designs cannot match. Three F120Q fans are included from the factory and arrive pre-installed at the front, so your build has meaningful positive pressure from the moment you power it The case accepts motherboards from Mini-ITX all the way up to E-ATX (up to 277mm width), making it a practical long-term chassis for a wide range of platform upgrades. SGCC steel forms the structural shell, while a dark-tinted tempered glass side panel provides a clear view of the interior without the haze of cheaper alternatives. Radiator options are genuinely generous. The front can house a radiator up to 420mm, and the top supports up to 360mm — figures that accommodate most 360mm and custom-loop setups with headroom to spare. A single 120mm or 140mm slot at the rear rounds out the cooling layout. The mesh panels covering the front and top intake areas prioritise air movement over noise isolation, a deliberate trade-off for builders who run thermally demanding hardware. Cable routing is handled through wide management channels at the rear, supplemented by built-in hooks and included straps. Up to 34.5mm of cable management clearance is available behind the motherboard tray. The top I/O panel provides two USB 3.2 Gen 1 Type-A ports, one USB 3.2 Gen 2x2 Type-C port (20 Gbps), and a headset audio jack — all accessible without reaching around to the rear of the desk. Tool-less panel removal applies to the front, top, and side panels. Storage capacity covers two 3.5-inch drive bays and four 2.5-inch SSD mounts (2+2 configuration). Seven expansion slots accommodate multi-GPU or high-card-count builds, and GPU clearance extends to 410mm. The PSU bay accepts units up to 200mm in length. — Verified Specifications — Form factor: E-ATX (up to 277mm), ATX, Micro-ATX, Mini-ITX Dimensions (H × W × D): 544mm × 244mm × 468mm Material: SGCC Steel, Dark Tinted Tempered Glass Pre-installed fans: 3 × F120Q 120mm (front); 1,350 ±150 RPM; 60.2 CFM; 24.1 dBA; 3-pin DC Total fan capacity: 10 (3 front, 3 top, 3 bottom, 1 rear) Front fan/radiator: 3 × 120mm or 3 × 140mm / up to 420mm radiator Top fan/radiator: 3 × 120mm or 2 × 140mm / up to 360mm radiator Bottom fan: 3 × 120mm Rear fan/radiator: 1 × 120mm or 1 × 140mm / up to 140mm radiator CPU cooler clearance: up to 185mm GPU clearance: up to 410mm PSU clearance: up to 200mm Cable management clearance: up to 34.5mm Top radiator + fan combined thickness: up to 57mm I/O: 2 × USB 3.2 Gen 1 Type-A, 1 × USB 3.2 Gen 2x2 Type-C (20 Gbps), 1 × headset audio jack Expansion slots: 7 Drive bays: 2 × 3.5-inch HDD, 4 × 2.5-inch SSD Warranty: 2 years
