SAPPHIRE Radeon Pure RX 9060 XT OC White 16GB AMD Graphic Card

The Sapphire Pure Radeon RX 9060 XT OC White 16GB is a 1440p-focused graphics card built on AMD’s RDNA 4 architecture, delivering strong rasterisation, hardware ray-tracing, and AI-accelerated upscaling in a clean all-white form factor. Powered by 32 Compute Units with 2048 Stream Processors, the card boosts up to 3290 MHz and maintains a game clock of up to 2700 MHz, while the 16 GB GDDR6 framebuffer on a 128-bit bus running at 20 Gbps effective keeps textures and assets off-chip pressure at 1440p. Sapphire’s thermal engineering on the Pure line centres on the Free Flow heatsink — an axial-fan design that channels airflow through optimised fin arrays to reduce turbulence and improve heat transfer. AeroCurve fan blades refine airflow and static pressure while keeping noise in check, and the Dual Ball Bearing fans extend operational lifespan compared to sleeve-bearing equivalents. Honeywell PTM7950 phase-change Thermal Interface Material sits between die and heatspreader, a premium choice that lowers junction temperatures under sustained load. Composite heatpipes distribute heat evenly across the cooling module, which makes direct contact with the GPU, GDDR6 memory, and VRMs through an Integrated Cooling Module design. The PCB is a high-density 10-layer, 2 oz copper build with a High TG rating, supporting the card’s 9-Phase Digital Power Design and built-in fuse protection on the PCIe power connector. The FrameDefense box-frame chassis and all-aluminium backplate add structural rigidity and resist flex during installation. An ARGB Sapphire logo and 3-pin external ARGB header allow synchronisation with motherboard RGB ecosystems via compatible software. On the feature side, AMD FSR 4 with AI upscaling, Fluid Motion Frames 2, Anti-Lag 2, AV1 encode/decode, DisplayPort 2.1a, AMD FreeSync, and DirectX 12 Ultimate are all supported. Sapphire TriXX software enables Performance vs. Efficiency Quicksets, TriXX Boost, and Glow! lighting control. Verified Specifications: – GPU: AMD Radeon RX 9060 XT (RDNA 4) | Product Code: 11350-02-20G – Stream Processors: 2048 | Compute Units: 32 (3rd-Gen RT + 2nd-Gen AI Accelerators) – Ray Accelerators: 32 | AI Accelerators: 64 – Boost Clock: up to 3290 MHz | Game Clock: up to 2700 MHz – Memory: 16 GB GDDR6, 128-bit bus, 20 Gbps effective – Infinity Cache: 32 MB – TDP: 170 W Typical Board Power – Outputs: 2× HDMI, 1× DisplayPort 2.1a (max 3 displays, up to 7680×4320) – Interface: PCIe 5.0 x16 – Form Factor: 2.3-slot ATX | Dimensions: 240 mm × 124 mm × 46.1 mm – Power Connector: 1× 8-pin | Minimum PSU: 450 W – OS Support: Windows 10/11 64-bit, Linux
