Thermaltake AX500 SSI-EEB Full Tower Case – Dual 420mm Radiator Support & 14-Fan Capacity

The Thermaltake AX500 is a full tower chassis engineered for demanding high-performance workstations and enthusiast gaming builds. Built from SPCC steel and tempered glass with a clean black finish, it accommodates the widest range of motherboard form factors available — from Mini-ITX all the way up to SSI-EEB and SSI-CEB — making it a natural home for server-grade and HEDT platforms alike. Cooling sits at the heart of the AX500's design. Four 140mm CT140 fans come pre-installed and ready to move air from day one. When more cooling capacity is needed, the chassis scales up to fourteen 120mm or nine 140mm fans spread across the front, top, rear, right panel, and PSU cover positions. Liquid cooling is equally well catered for: dual 420mm or 360mm radiators can be mounted simultaneously at the front and top, with the top position supporting radiators up to 82mm in combined fan-plus-radiator thickness. A 120mm or 140mm rear radiator round out the options, giving builders exceptional flexibility for complex custom or AIO loop configurations. Hardware clearances are generous throughout. CPU coolers up to 185mm tall fit without issue, discrete graphics cards up to 460mm long are supported, and power supplies up to 200mm in length can be installed. A built-in GPU holder prevents sagging under the weight of large multi-slot graphics cards. Storage is handled by two drive cages beneath the PSU cover that collectively accommodate up to four 3.5-inch hard drives, plus a dedicated drive plate behind the motherboard tray for one additional 3.5-inch or two 2.5-inch drives. In total the chassis supports up to five 3.5-inch HDDs and six 2.5-inch SSDs. Cable management benefits from ample routing clearance behind the motherboard tray, multiple anchor points, and included Velcro straps and cable ties. Dust protection is comprehensive, with filters at the front, top, and bottom intake positions. The I/O panel provides a USB 3.2 Gen 2 Type-C port, a USB 3.0 port, and HD audio connectivity. Eight expansion slots serve multi-card and high-card-count builds. Verified Specifications: - Form Factor: Full Tower - Motherboard Support: Mini-ITX, Micro-ATX, ATX, E-ATX, SSI-CEB, SSI-EEB (hidden-connector support for Micro-ATX and ATX) - Material: SPCC Steel, Tempered Glass - Color: Black - Pre-installed Fans: 4x 140mm CT140 - Max Fan Support: 14x 120mm or 9x 140mm - Max Radiator Support: Dual 420mm (front + top); also 360mm, 280mm, 240mm, 140mm, 120mm - Max GPU Length: 460mm - Max CPU Cooler Height: 185mm - Max PSU Length: 200mm - Drive Bays: Up to 5x 3.5-inch HDD, up to 6x 2.5-inch SSD - Expansion Slots: 8 - I/O Panel: USB 3.2 Gen 2 Type-C, USB 3.0, HD Audio - Dust Filters: Front, Top, Bottom - Warranty: 3 Years - SKU: CA-11D-00F1WN-00
