Thermaltake AX700 TG Workstation Super Tower Case (CA-11B-00F1WN-00)

The Thermaltake AX700 TG Super Tower Chassis (SKU: CA-11B-00F1WN-00) is a large-format workstation enclosure built for professionals who need maximum expandability in a single chassis. Constructed from SPCC steel with a black finish, it accommodates some of the most demanding hardware configurations available today. On the motherboard side, the AX700 TG supports XL-ATX, SSI-EEB, SSI-CEB, E-ATX, ATX, Micro-ATX, and Mini-ITX form factors — making it compatible with high-end HEDT and server-grade platforms. The chassis can house up to five 2-slot graphics cards and offers a maximum GPU clearance of 630 mm when the HDD rack is removed, or 360 mm with the HDD rack in place. Cooling headroom is a defining feature of this chassis. Up to 18 fans (120 mm or 140 mm) can be installed across the front, top, bottom, and side positions. AIO liquid cooling up to 420 mm is supported, while the top can accommodate a DIY custom loop radiator up to 560 mm. The perforated right side panel further assists passive airflow, while dust filters on the front, bottom, and side positions help keep the system clean. Storage capacity is equally generous: the AX700 TG supports up to 18 × 3.5-inch hard drives and up to 18 × 2.5-inch SSDs via its combination of HDD cages and trays. Ten expansion slots provide room for additional PCIe cards alongside multi-GPU setups. Access and installation are made easier through Thermaltake's Dismantlable Modular Design (DMD), which eliminates hard-to-reach screw locations by allowing key panels and brackets to be fully removed. The hinged tempered glass left panel provides a clear view of the interior, while the right panel swings open for quick right-side access. A built-in GPU holder prevents graphics card sag under the weight of multiple large cards. The front I/O panel includes USB 3.2 Gen 2 Type-C, USB 3.0, and HD Audio ports. The chassis also supports stacking with the separately sold Thermaltake AX100 pedestal for expanded liquid cooling, additional storage, or dual-system configurations. Verified Specifications: - Form factor support: XL-ATX, SSI-EEB, SSI-CEB, E-ATX, ATX, M-ATX, Mini-ITX - Dimensions: 645 × 324.6 × 685 mm - Material: SPCC steel, Black - Max fan support: 18 × 120 mm / 140 mm - AIO radiator support: up to 420 mm - DIY radiator support: up to 560 mm - Max GPU length: 630 mm (without HDD rack) / 360 mm (with HDD rack) - Max CPU cooler height: 190 mm - Max PSU length: 220 mm; PSU type: ATX PS/2 - Max 3.5" HDD: 18 | Max 2.5" SSD: 18 - Expansion slots: 10 - Dust filters: Front, Bottom, Side - I/O: USB 3.2 Gen 2 Type-C, USB 3.0, HD Audio - Warranty: 2 Years
