Thermaltake Core P6 Tempered Glass ATX Mid Tower Case (CA-1V2-00M1WN-00)

The Thermaltake Core P6 TG (model CA-1V2-00M1WN-00) is a transformable ATX mid tower chassis built for enthusiasts who want both visual impact and serious cooling flexibility. Part of Thermaltake's iconic open-frame Core Series, the Core P6 TG ships with Tt LCS Certification, confirming readiness for advanced custom liquid-cooling loops. The chassis supports two distinct form configurations: a traditional closed-panel layout using all three included 4mm tempered glass panels, or an open-frame presentation once the front and top panels are removed. Two placement orientations are available — standard vertical desktop use or wall-mounted display — giving builders genuine flexibility in how they showcase their systems. Cooling performance is a primary design goal. The case accepts up to thirteen 120mm or eight 140mm fans across the front, top, rear, right motherboard side, and bottom positions. Radiator support extends to 360mm or 280mm units at the front, top, and right motherboard side, and up to 240mm at the bottom, making multi-radiator custom loop builds achievable within a mid-tower footprint. CPU coolers up to 180mm tall are accommodated. Seven expansion slots feature a rotatable patented design, allowing graphics cards to be displayed horizontally or vertically without third-party riser hardware. GPU clearance reaches 458mm without a radiator installed, accommodating modern high-end discrete cards. An integrated PSU cover conceals cabling for a cleaner interior presentation, and an included L-shaped GPU support bracket reduces mechanical stress on the PCIe slot. Storage and I/O are well-provisioned. Drive bays support four 3.5-inch HDDs or up to eight 2.5-inch SSDs. The front-right I/O panel provides one USB 3.2 Gen 2 Type-C port, two USB 3.0 ports, two USB 2.0 ports, and HD audio in/out. Three magnetic dust filters at the right, top, and bottom positions simplify maintenance. The Dismantlable Modular Design (DMD) system allows panels, racks, and brackets to be removed and repositioned, supporting custom mod builds. Thermaltake also provides downloadable 3D-printable accessory files for further personalisation. Verified Specifications: - Part Number: CA-1V2-00M1WN-00 - Form Factor: Mid Tower - Supported Motherboards: Mini-ITX, Micro-ATX, ATX, CEB - Dimensions (H x W x D): 565 x 255 x 530 mm - Net Weight: 17.84 kg (39.33 lbs) - Side Panels: 4mm Tempered Glass x3; Tempered Glass x2 Black - Material: SPCC steel, tempered glass - Expansion Slots: 7 (rotatable patented design) - Max Fan Support: 13x 120mm or 8x 140mm (combined positions) - Max Radiator: 360mm (front, top, right); 280mm (front, top, right); 240mm (bottom) - CPU Cooler Height Limit: 180mm - GPU Length Limit: 458mm (without radiator) - PSU Length Limit: 200mm; Standard PS2 PSU (optional, not included) - Drive Bays: 4x 3.5-inch HDD or 8x 2.5-inch SSD - I/O: USB 3.2 Gen 2 Type-C x1, USB 3.0 x2, USB 2.0 x2, HD Audio x1 - Dust Filters: Magnetic, at top, right, and bottom - Warranty: 3 Years
