Thermaltake Smart BX1 750W 80 Plus Bronze SMPS

Features Smart BX1 750W Built to deliver 80 PLUS Bronze with 88% power efficiency, the Smart BX1 series is available in 450W – 750W models. Constructed with a 120mm hydraulic bearing fan, Japanese main capacitors and other premium components to help deliver a continuous and stable power output at 40℃, near silent operation and reliable performance. With an ample 5-year warranty, the Smart BX1 is able to satisfy the market, where value-oriented users are looking for a new power supply with all the latest features. Ultra Quiet 120mm Hydraulic Bearing Fan Featuring a 120mm hydraulic bearing fan with intelligent RPM controls to help guarantee superior cooling performance and near silent operation. Low Ripple Noise All ripples are lower than 80mV on +12V, and lower than 40mV on +5V or +3.3V from 0% to 100% load to ensure a stable operation and keep your performance-critical components, such as high-end graphics cards, to function reliably for longer. Premium Japanese Main Capacitor Providing great durability as well as offering the highest stability, while remaining reliable. High Amperage Single +12V Rail Powerful single +12V rail ensures a stable and reliable supply to other PC components. Multiple Connectors Soft black cables come with sleeve cabling, designed to make cable installation an easy task while fully powering the system at optimal voltages 80 PLUS Gold Certified and Intel C6/C7 States Ready Smart BX1 series saves energy through its high energy efficiency up to 88% and is certified to 80 PLUS® Bronze. It has been optimized to work with all generations of Intel’s processors to achieve maximum energy saving. Specifications P/N PS-SPD-0750NNSABD-1 WATTS 750W RGB FAN No FORM FACTOR ATX MODEL SPD-750AH2NKB TYPE ATX 12V v2.3 and EPS v2.92 MAX. OUTPUT CAPACITY 750W PEAK OUTPUT CAPACITY 900W COLOR Black DIMENSION ( W / H / D ) 150mm(W) x 86mm(H) x 140mm(D) PFC (POWER FACTOR CORRECTION) Active PFC POWER GOOD SIGNAL 100-500 msec HOLD UP TIME > 16msec at 70% of full load INPUT CURRENT 12A max. INPUT FREQUENCY RANGE 50Hz – 60Hz INPUT VOLTAGE 100V – 240V~ OPERATING TEMPERATURE 5°C to + 40°C OPERATING HUMIDITY 20% to 85%, non-condensing STORAGE TEMPERATURE -40°C to + 55°C STORAGE HUMIDITY 10% to 95%, non-condensing COOLING SYSTEM 12cm Hydraulic bearing fan EFFICIENCY Meet 80 PLUS®Bronze at 115Vac input. MTBF 100,000 hrs minimum SAFETY APPROVAL CE/CB/TUV/ UL/ FCC/ BSMI PCI-E 6+2PIN 4 Warranty 5 Years Note *** Features, Price, Specifications are subject to change without notice
