ZOTAC Gaming GeForce RTX 5060 Ti Twin Edge 8GB Nvidia Graphic Card

The ZOTAC Gaming GeForce RTX 5060 Ti Twin Edge 8GB is a compact, high-performance graphics card built on the NVIDIA Blackwell architecture. Designed for gamers and creators who want capable performance in a small form factor, this card fits into most mid-tower and small form factor cases without compromise. At its core, the RTX 5060 Ti Twin Edge carries 4608 CUDA cores and 8GB of GDDR7 video memory on a 128-bit memory bus, with a memory speed of 28 Gbps. The GPU boost clock is rated at 2572 MHz, giving it strong single-card performance for 1080p and 1440p gaming workloads. The card connects via a PCIe 5.0 x8 interface, keeping it compatible with the latest and current-generation motherboards. NVIDIA DLSS 4 with Multi Frame Generation support allows the card to use AI-driven frame rendering to boost effective frame rates in supported titles, while NVIDIA Reflex 2 with Frame Warp technology helps reduce system latency for competitive play. Full ray tracing is accelerated by fourth-generation RT Cores, and fifth-generation Tensor Cores power the neural rendering pipeline. Display connectivity is handled by three DisplayPort 2.1b outputs with UHBR20 support — capable of driving up to 4K at 480 Hz or 8K at 165 Hz with DSC — and one HDMI 2.1b port supporting 4K at 480 Hz HDR or 8K at 120 Hz HDR with DSC. Up to four displays can be connected simultaneously. HDCP 2.3 is supported. The IceStorm 2.0 cooling solution uses dual BladeLink fans across a 2-slot profile. A metal backplate adds structural rigidity. The card measures 220.5 mm × 120.25 mm × 41.6 mm, making it genuinely SFF-ready. Power delivery requires a single 8-pin PCIe connector, and ZOTAC recommends a minimum 600 W power supply. Total board power is 180 W. Software support includes ZOTAC’s FireStorm utility for monitoring and tuning clock speeds, memory frequencies, fan curves, and white LED lighting. The card supports Microsoft DirectX 12 Ultimate, OpenGL 4.6, NVIDIA G-SYNC, and is compatible with Windows 10 64-bit (v1809 or later) and Windows 11. Verified Specifications: • GPU: NVIDIA GeForce RTX 5060 Ti (ZT-B50610E-10M) • CUDA Cores: 4608 • Video Memory: 8 GB GDDR7 • Memory Bus: 128-bit • Memory Clock: 28 Gbps • Engine Clock: 2572 MHz • Interface: PCIe 5.0 x8 • Display Outputs: 3× DisplayPort 2.1b (UHBR20), 1× HDMI 2.1b • Max Resolution: 4K 480 Hz / 8K 165 Hz (DP, DSC) • Multi-Display: Quad Display • TBP: 180 W • Power Connector: 1× 8-pin • Recommended PSU: 600 W • Slot Width: 2-slot • Dimensions: 220.5 × 120.25 × 41.6 mm • DirectX: 12 Ultimate | OpenGL: 4.6 | HDCP: 2.3 • OS: Windows 10 64-bit (v1809+), Windows 11
