ZOTAC Gaming Geforce RTX 5060 Ti Twin Edge OC White 16GB NVIDIA Graphic Card
MPN ZOTAC-GAMING-GEFORCE-RTX-5060-TI-TWIN-EDGE-7cc9e3 · Brand Zotac
The ZOTAC Gaming GeForce RTX 5060 Ti Twin Edge OC White Edition pairs NVIDIA's Blackwell architecture and DLSS 4 with 16 GB of GDDR7 memory in a compact, SFF-ready dual-fan design with a single 8-pin power connector
Inclusive of GST · GST invoice available
Overview
The ZOTAC Gaming GeForce RTX 5060 Ti Twin Edge OC White Edition is a compact, SFF-ready graphics card built on NVIDIA's Blackwell architecture and supporting DLSS 4 — the latest generation of AI-accelerated frame generation and upscaling technology. Designed for gamers who want capable mid-range performance in a space-efficient package, this white-coloured GPU fits neatly into slim chassis and small-form-factor builds while delivering a factory overclocked boost clock of 2602 MHz out of the box. At the heart of this card is 16 GB of GDDR7 memory running at 28 Gbps across a 128-bit interface, providing ample headroom for high-resolution textures and modern workloads. The card connects via PCIe Gen 5 and requires only a single 8-pin PCIe power connector, with a recommended PSU of 600 W — making it a practical upgrade choice for users who do not wish to overhaul their entire power delivery setup. Cooling is handled by ZOTAC's IceStorm 2.0 solution, which combines twin BladeLink fans with a full-length heatsink, composite heatpipes featuring a thicker envelope, multi-channel working fluid, and a grooved wick structure for efficient heat transfer. The FREEZE Fan Stop feature lets both fans idle at zero RPM during light workloads, reducing noise. A metal backplate adds structural rigidity and a premium finish consistent with the white aesthetic. The card supports up to four simultaneous displays at resolutions up to 7680 x 4320 (8K) via HDMI and DisplayPort outputs, and is compatible with DirectX 12 Ultimate and OpenGL 4.6. Its compact 2-slot, approximately 220.5 mm length makes it one of the most case-compatible cards in the RTX 50 series lineup. Verified Specifications: - GPU: NVIDIA GeForce RTX 5060 Ti (Blackwell) - CUDA Cores: 4608 - Memory: 16 GB GDDR7, 128-bit, 28 Gbps - Boost Clock: 2602 MHz (factory OC) - PCI Express: Gen 5 - Power Connector: 1 x 8-pin - Recommended PSU: 600 W - Display Outputs: HDMI, DisplayPort (up to 4 displays) - Max Resolution: 7680 x 4320 - DirectX: 12 Ultimate | OpenGL: 4.6 - Cooler: Dual fan (IceStorm 2.0, FREEZE Fan Stop) - Form Factor: 2-slot, ~220.5 mm (SFF-ready) - Product Code: ZT-B50620Q-10M - Warranty: 3+2 Years
Datasheet
| Memory Type | GDDR7 |
|---|---|
| Warranty | 5 Years |
| Chipset | NVIDIA GEFORCE |
| Memory Size | 16 GB |
| GPU | RTX 5060 Ti |
| Memory Clock | 28 Gbps |
| Recommended PSU | 600W |
| Resolution | 7680 x 4320 |
| Ports | HDMI,DisplayPort |
| Cooler | Dual Fan |
| Note** | Features, Price and Specifications are subject to change without notice. Images used for Representation Purpose Only |
| Opengl | 4.6 |
| Directx | 12 Ultimate |
| Pci Express | 5 |
| Engine Clock | 2602 MHz |
| Product Code | ZT-B50620Q-10M |
| Memory Interface | 128-BIT |
| Power Connectors | 1 x 8-pin |
| Max Display Support | 4 |
| GPU Core (Cuda Core) | 4608 |
