Alseye M90 ARGB 92mm CPU Air Cooler

The ALSEYE M90 ARGB is a compact twin-tower CPU air cooler built for builders who want efficient thermal management without sacrificing aesthetics. Its asymmetric tower design deliberately reduces the air-exhaust tower size while enlarging the air-intake tower, increasing usable fin surface area and promoting more effective airflow through the heatsink stack compared to symmetrical twin-tower layouts. At the heart of the M90 are four 6 mm direct-contact copper heatpipes that sit flush against the CPU integrated heat spreader. This heatpipe direct-contact design shortens the thermal path from processor to fins, allowing heat to transfer rapidly across the aluminium fin array. The entire heatsink and fan frame receive a uniform black spray finish, giving the cooler a clean, cohesive look inside windowed cases. The bundled 92 × 92 × 25 mm PWM fan runs between 800 and 2400 RPM, delivering up to 40.5 CFM of airflow at a static pressure of 2.51 mm/H₂O. Noise output is rated at 28 dB(A). The hydraulic bearing extends operational life while keeping operating sound low under typical desktop workloads. Fan control uses a standard PWM 4-pin header, and a separate ARGB connector links to compatible motherboard ARGB headers or included controllers for synchronised lighting. A Molex 4-pin adapter is also included for systems without a dedicated fan header. The ARGB top cover features a diamond-cut line pattern that diffuses addressable RGB light across the cooler crown, visible through side-panel glass in a darkened environment. Broad socket compatibility means the M90 fits into Intel LGA 775, 1150, 1151, 1155, 1156, 1366, 2011, 2011-v3, 1200, and 1700 platforms, as well as AMD FM1, FM2, AM2, AM2+, AM3, AM3+, and AM4. Note that LGA 1700 support is listed as optional in the source documentation — confirm bracket inclusion at purchase. Verified Specifications: • Model: M90 | Series: MAX • Dimensions: 112 × 92 × 135 mm • Heatsink net weight: 564.7 g | Gross weight (boxed): 802.2 g • Heatpipes: 4 × Ø6 mm copper direct-contact • Fan size: 92 × 92 × 25 mm • Fan speed: 800–2400 RPM (PWM) • Airflow: 40.5 CFM • Static pressure: 2.51 mm/H₂O • Noise level: 28 dB(A) • Bearing: Hydraulic • Fan connector: PWM 4-pin + ARGB + Molex 4-pin • Rated voltage: 12 V | Rated current: 0.11 A | Power: 1.32 W • Warranty: 1 year
