AMD Ryzen 9 9950X3D2 Processor with Radeon Graphics

The AMD Ryzen 9 9950X3D2 Dual Edition Desktop Processor is a 16-core, 32-thread Ryzen 9000-series CPU built on the Zen 5 architecture and equipped with AMD’s Dual 3D V-Cache technology. Stacked L3 cache is present on both core complexes, which is intended to keep gaming performance and cache-heavy workstation tasks consistent across all 16 cores rather than relying on software scheduling to pin work to a single cache-rich CCD. The processor runs at a 4.3 GHz base clock and boosts up to 5.6 GHz on demand, with a 200 W TDP and a maximum operating temperature of 95 degrees Celsius. Total cache stands at 208 MB – 16 MB of L2 paired with 192 MB of L3 – giving demanding games, simulations, and AI inference workloads ample low-latency memory to draw The multiplier is unlocked, so manual tuning and PBO-style boost adjustments are available on supported boards. Connectivity is built on the modern AM5 platform: DDR5 memory support up to 256 GB, PCIe 5.0, and broad chipset compatibility across A620, B650, B650E, B840, B850, X670, X670E, X870, and X870E motherboards. Integrated AMD Radeon Graphics with 2 graphics cores running at up to 2200 MHz handle display output and lightweight visual tasks without requiring a discrete GPU during build, troubleshooting, or office workloads. A CPU cooler is not included in the box, so plan on a capable AIO or high-end tower air cooler sized for a 200 W class chip. AMD lists official OS support for Windows 11 64-bit, Windows 10 64-bit, RHEL x86 64-bit, and Ubuntu x86 64-bit; check the AMD product page for the most current list. The unit ships with a 3-year manufacturer warranty as listed by the source distributor. Verified specifications: – Cores / Threads: 16 / 32 – Base clock: 4.3 GHz – Max boost clock: 5.6 GHz – Total cache: 208 MB (16 MB L2 + 192 MB L3) – TDP: 200 W – Socket: AM5 – Memory: DDR5, up to 256 GB – Integrated graphics: AMD Radeon Graphics (2 cores, up to 2200 MHz) – Architecture: Zen 5 with Dual 3D V-Cache – Multiplier: Unlocked – Cooler included: No – Max operating temperature: 95 degrees Celsius – Warranty: 3 years
