Arctic Freezer 36 CPU Air Cooler

The ARCTIC Freezer 36 (ACFRE00121A) is a single-tower CPU air cooler designed for builders who want reliable, quiet, and efficient thermal management across Intel and AMD platforms. It ships with two 120 mm P12 PWM PST fans arranged in a push-pull configuration, drawing air through 59 closely spaced aluminium fins mounted on four 6 mm copper heatpipes. The result is thorough heat dissipation even under sustained processor loads, while keeping acoustic output in check thanks to ARCTIC’s fluid dynamic bearing technology—developed with a German-engineered alloy-and-lubricant combination that minimises friction, wear, and bearing noise over the long term. The heatsink’s fin stack is open at the sides, enabling the rear fan to draw supplementary cool air from inside the chassis through the heatsink. This side-flow geometry improves overall case ventilation rather than simply recirculating warm air. Both fans attach to the heatsink via a tool-free click system, eliminating traditional wire clips and making fan installation or replacement straightforward—even with the cooler already mounted in a case. The Freezer 36 is compatible with most standard 120 mm fans, giving you flexibility for future upgrades. ARCTIC includes a custom contact-frame for Intel LGA1700 and LGA1851 sockets. This frame replaces Intel’s Independent Loading Mechanism (ILM), which can exert over 40 kg of force and introduce mechanical stress on the CPU die, solder layer, and PCB. The ARCTIC frame spreads mounting load more evenly, reduces long-term mechanical fatigue on the motherboard and processor, and allows the cooler to be screwed directly to the backplate for a secure, repeatable mount. AMD AM5 and AM4 mounting hardware is also included. The package includes 0.8 g of ARCTIC MX-6 thermal interface material. The aluminium top plate conceals the soldered heatpipe ends for a cleaner aesthetic, and the cooler’s dimensions (104 mm L × 126 mm W × 159 mm H) keep it compatible with most mid-tower and full-tower cases. A 6-year manufacturer warranty backs the product. Verified Specifications: • Model: Freezer 36 | SKU: ACFRE00121A • Socket Support: Intel LGA1851, LGA1700 | AMD AM5, AM4 • Cooler Dimensions: 104 (L) × 126 (W) × 159 (H) mm | Weight: 890 g • Heatpipes: 4× 6 mm diameter, copper • Fin Stack: 59 fins × 0.4 mm, aluminium • Fans: 2× P12 PWM PST, 120 mm • Fan Speed: 200–1800 rpm, PWM controlled (0 rpm below 5% PWM duty) • Bearing: Fluid Dynamic Bearing • Electrical: 0.10 A | 12 V DC • Connector: 4-Pin PWM + 4-Pin PST plug • Cable: 200 mm + 80 mm splitter • TIM Included: MX-6 (0.8 g) • Operating Ambient Temperature: 0–40 °C • PI/NNPI: 250/234 W • Warranty: 6 years
