ASUS ROG Crosshair X670E Hero DDR5 AMD Motherboard

The ASUS ROG Crosshair X670E Hero is a full-size ATX motherboard built on the AMD X670E chipset, designed exclusively for AMD Ryzen 7000 Series processors in the AM5 socket. It is an enthusiast-grade platform that combines robust power delivery with extensive connectivity and a dual-chipset architecture to serve demanding builders and overclockers alike. At the heart of the board's performance story is its eighteen-phase 110A-per-stage power solution, engineered to sustain the high sustained loads that AMD's Ryzen 7000 Series processors demand. Massive VRM heatsinks are positioned to maximise thermal dissipation, and both chipsets share a large central thermal plate to draw heat away efficiently. The five M.2 slots each carry their own heat spreader, allowing PCIe 5.0 NVMe drives to run at peak bandwidth without throttling. Memory support spans four DDR5 DIMM slots in dual-channel configuration, with a maximum capacity of 128 GB. Native JEDEC speeds start at DDR5-4800, with overclocked profiles reaching DDR5-6400 and beyond via XMP/DOCP, supporting both ECC and non-ECC unbuffered memory. On the expansion side, two PCIe 5.0 x16 slots accommodate the latest discrete graphics cards, while one PCIe 4.0 x1 slot covers legacy peripherals. Connectivity is anchored by WiFi 6E, Intel 2.5 Gb Ethernet (protected by ASUS LANGuard), and dual USB4 ports on the rear I/O. An HDMI output and Optical S/PDIF output are also present. Audio is handled by the ROG SupremeFX solution using the ALC4082 codec with an ESS quad-DAC amplifier, delivering 7.1-channel surround-sound capability. Storage options extend to six SATA 6 Gb/s ports alongside the five M.2 slots. Personalisation is enabled through Polymo Lighting on the I/O shroud — a microstructural lighting array offering two switchable patterns configurable via ASUS Armoury Crate software, which also synchronises with ARGB ecosystem components. Verified Specifications: - Form Factor: ATX - Socket: AM5 - Chipset: AMD X670E (dual-chipset design) - CPU Compatibility: AMD Ryzen 7000 Series Desktop Processors - Memory: 4 x DDR5 DIMM, dual-channel, up to 128 GB; DDR5-4800 native, DDR5-6400+ (OC), ECC and non-ECC unbuffered - PCIe Slots: 2 x PCIe 5.0 x16, 1 x PCIe 4.0 x1 - M.2 Slots: 5 (with individual heat spreaders) - SATA: 6 x SATA 6 Gb/s - LAN: Intel 2.5 Gb Ethernet - Wireless: WiFi 6E - USB: Dual USB4 (rear I/O) - Audio: ROG SupremeFX ALC4082, 7.1-channel, ESS quad-DAC amplifier - Display Output: 1 x HDMI - Digital Audio Out: 1 x Optical S/PDIF - Power Connector: 24-pin ATX - Lighting: Polymo Lighting (I/O shroud), ARGB-compatible
