Colorful Battle-AX B450M-T M.2 V14 M-ATX Motherboard
MPN BA-B450M-T-M-2-V14 · Brand COLORFUL · mATX
COLORFUL Battle-AX B450M-T M.2 V14 is a Micro-ATX motherboard on the AMD AM4/B450 platform supporting Ryzen 5000 CPUs, dual-channel DDR4 up to 64 GB, PCIe M.2 storage, HDMI 4K output, and Gigabit LAN
Inclusive of GST · GST invoice available
Overview
The COLORFUL Battle-AX B450M-T M.2 V14 is an AMD AM4 platform Micro-ATX motherboard built around the B450 chipset, designed to pair with AMD Ryzen 5000, Ryzen 5000-G, and Ryzen 4000-G series processors. Its compact Micro-ATX form factor makes it a practical choice for space-conscious builds without sacrificing the core connectivity users rely on every day. For storage, the board provides one PCIe 3.0 x4 M.2 slot (M.2_1) supporting 2242, 2260, and 2280 form-factor SSDs via the CPU channel, alongside four SATA 6 Gb/s ports for traditional drives. Memory support extends to dual-channel DDR4 at speeds up to DDR4-3600 with XMP profile compatibility, and the board accepts up to 64 GB of total RAM across its memory slots. Display output is handled through both an HDMI 2.0 port—capable of driving a display at up to 4K 60 Hz resolution—and a legacy VGA port, giving users flexibility when connecting monitors old and new. Networking is managed by a Realtek RTL8111H Gigabit Ethernet controller, while audio is powered by a Realtek ALC897 chip supporting 7.1-channel high-fidelity decoding. Expansion is covered by one PCIe 3.0 x16 slot for a discrete graphics card and one PCIe 3.0 x1 slot for additional peripherals. The rear I/O panel includes four USB 2.0 ports, two USB 3.2 Gen 1 Type-A ports, a PS/2 combo port, Gigabit LAN, HDMI, VGA, and three audio jacks. Internally, headers are provided for additional USB 2.0 and USB 3.2 Gen 1 expansion, front-panel audio, COM port, speaker, Clear CMOS, and a debug light connector. Power management features include S3/S4 sleep wake-up, network S5 wake-up, USB wake-up, scheduled boot, and timed boot. The hardware monitor tracks CPU and system fan speeds (both controllable), CPU and system temperatures, and per-group voltage readings. COLORFUL backs this board with a 3-year warranty. --- Verified Specifications --- Socket: AMD AM4 Chipset: AMD B450 Form Factor: Micro-ATX Supported CPUs: Ryzen 5000, Ryzen 5000-G, Ryzen 4000-G Memory: Dual-channel DDR4 up to DDR4-3600, max 64 GB, XMP support M.2 Slot: 1x PCIe 3.0 x4 (CPU channel), supports 2242/2260/2280 SATA Ports: 4x SATA 6 Gb/s Expansion: 1x PCIe 3.0 x16, 1x PCIe 3.0 x1 Rear USB: 4x USB 2.0, 2x USB 3.2 Gen 1 Type-A Display Output: 1x HDMI 2.0 (up to 4K 60Hz), 1x VGA Network: Realtek RTL8111H Gigabit Ethernet Audio: Realtek ALC897, 7.1-channel Warranty: 3 Years
Datasheet
| Warranty | 3 Years |
|---|---|
| Form Factor | mATX |
| Chipset | B450 |
| Socket | AM4 |
| CPU Type | Ryzen 5000, Ryzen 5000-G, Ryzen 4000-G |
| Max Memory | 64 GB |
| Memory Speed | up to 3600 |
| Platform | AMD |
| Memory Feature | Supports Extreme Memory Profile (XMP) memory technology Supports dual channel memory technology (* Please visit the official website of Colorful at http://www.colorful. cn for the latest memory compatibility list) |
| Expansion Slots | 1 PCIe 3.0 x16 slot 1 PCIe 3.0 x1 slot |
| Channel Supported | Dual Channel |
| Back Panel I/O Ports | 4×USB 2.0 interfaces 2×USB 3.2 Gen 1 Type-A interfaces 1×HDMI 2.0 interface, supporting up to 4K 60Hz resolution 1×VGA interface 1×PS/2 interface 1×Gigabit network interface 3×Audio interfaces (audio input/output/microphone) |
| Internal I/O Connector | 1×CPU fan pin 1×System fan pin 2×USB 2.0 pins expandable 4 USB 2.0 Type-A interfaces 1×USB 3.2 Gen 1 pin expandable 2 USB 3.2 Gen 1 Type-A interfaces 1×Front audio pin 1×Front panel pin 1×Speaker pin 1×COM port pin 1×Clear CMOS jumper 1×Debug light pin |
