Colorful H610M-D V20A M-ATX Motherboard

The Colorful H610M-D V20A is a Micro-ATX form factor motherboard built on Intel's H610 chipset for the LGA1700 socket. It supports Intel 12th, 13th, and 14th generation Core processors, making it a capable foundation for entry-level to mid-range desktop builds without requiring a platform upgrade when moving across supported CPU generations. Memory configuration is handled by two DDR4 DIMM slots supporting dual-channel operation with speeds up to DDR4 3200 MHz (also compatible with 2933, 2666, and 2400 MHz modules) and a maximum total capacity of 64 GB. For storage, the board provides four SATA 3.0 ports running at 6 Gbps and a single PCIe 3.0 x4 M.2 slot that accommodates both PCIe and SATA-based M.2 SSDs, enabling up to 32 Gbps sequential throughput on compatible NVMe drives. Expansion is handled by one PCIe 4.0 x16 slot for discrete graphics and one PCIe 3.0 x1 slot for additional peripherals. Display output on the rear panel includes an HDMI 2.0 interface supporting up to 4K at 60 Hz and a VGA port, which is useful for legacy monitor compatibility. Networking is delivered by a Realtek 8111H Gigabit Ethernet controller, providing a stable wired connection for demanding workloads and file transfers. Audio is managed by a Realtek ALC897 codec supporting up to 5.1-channel surround sound via three audio jacks on the rear panel. Connectivity on the rear I/O panel includes two USB 3.2 Gen 1 Type-A ports, four USB 2.0 Type-A ports, a Gigabit LAN port, and three audio jacks. Internal headers add further expandability with one USB 3.2 Gen 1 front-panel header (expandable to two additional Type-A ports) and one USB 2.0 header (expandable to two additional ports), along with CPU and system fan connectors, a front audio header, speaker pin, and a Clear CMOS jumper. The board carries a 3-year manufacturer warranty. Verified Specifications: - Socket: LGA1700 - Chipset: Intel H610 - CPU Support: Intel 12th / 13th / 14th Gen - Form Factor: Micro-ATX - Memory: 2× DDR4 DIMM, Dual-Channel, up to 64 GB, DDR4-3200/2933/2666/2400 MHz - Expansion: 1× PCIe 4.0 x16, 1× PCIe 3.0 x1 - Storage: 4× SATA 3.0 (6 Gbps), 1× PCIe 3.0 x4 M.2 (PCIe + SATA) - Rear I/O: 2× USB 3.2 Gen 1 Type-A, 4× USB 2.0, HDMI 2.0 (4K@60Hz), VGA, GbE LAN, 3× Audio - Front Headers: 1× USB 3.2 Gen 1 (2× ports), 1× USB 2.0 (2× ports), Front Audio, Front Panel, Speaker, Clear CMOS - LAN: Realtek 8111H Gigabit - Audio: Realtek ALC897, up to 5.1-channel - Warranty: 3 Years
