COOLER MASTER Master Air MA620M Dual Tower CPU Air Cooler (Black)
MPN CM-MA620M · Brand Cooler Master
Features of COOLER MASTER Master Air MA620M Dual Tower The COOLER MASTER MasterAir MA620M comes with dual blacked out aluminum towers with a uniform 6 heat pipe layout to dissipate the heat evenly... Dual Tower Heatsink A combination of 2 sets of heatsink allows bigger and more spread out surface area. The black paint enhances radiation cooling performance 6 Heatpipe Array Enhanced thermal conductivity and uniform layout distributes heat over more evenly across heatsinks. Easy Mounting System Ex
Inclusive of GST · GST invoice available
Overview
Features of COOLER MASTER Master Air MA620M Dual Tower
The COOLER MASTER MasterAir MA620M comes with dual blacked out aluminum towers with a uniform 6 heat pipe layout to dissipate the heat evenly...
Dual Tower Heatsink
A combination of 2 sets of heatsink allows bigger and more spread out surface area. The black paint enhances radiation cooling performance
6 Heatpipe Array
Enhanced thermal conductivity and uniform layout distributes heat over more evenly across heatsinks.
Easy Mounting System
Exclusive All-In-One mounting design for easy installation.
The New SF120R Fan
with silent driver IC and a wide range of speed settings, it can be used for silent operation or fine-tuned for maximum cooling performance.
Addressable RGB LED Controller
The wired Addressable RGB LED Controller allows for customizable colors and effects with just the touch of a button. software.
Lighting Badge
The Cooler Master hexagon logo and embedded Addressable RGB lighting strip provides unique perspective light effect.
Specifications of COOLER MASTER Master Air MA620M Dual Tower
| Model | MAM-D6PN-120PA-R1 |
| CPU Socket | LGA2066, LGA2011-v3, LGA2011, LGA 1200, LGA1151, LGA1150, LGA1155, LGA1156, AM4, AM3+, AM3, AM2+, AM2, FM2+, FM2, FM1 |
| Dimensions (L x W x H) | 135 x 125 x 165 mm / 5.3 x 4.9 x 6.5 inch |
| Heat Sink Material | 6 Heat Pipes, Aluminum Fins |
| Fan Dimensions | 120 x 120 x 25 mm / 4.7 x 4.7 x 1 inch |
| Fan Quantity | 1 PCS |
| Fan Speed | 650-2000 RPM (PWM) ± 10% |
| Fan Airflow | 57.3 CFM (Max) |
| Fan Air Pressure | 2.0 mmH2O (Max) |
| Fan MTTF | 160,000 Hours |
| Fan Noise Level | 8 - 30 dBA |
| Fan Power Connector | 4-Pin (PWM) |
| Fan Rated Voltage | 12V DC |
| Fan Rated Current | 0.16A |
| Fan Safety Current | 0.37A |
| Fan Power Consumption | 1.92W |
| Series | MasterAir |
| Cooler Type | Air Cooler |
| Warranty | 5 Years |
| Note | ***Features, Price and Specifications are subject to change without notice. |
Datasheet
| Warranty | 5 Years |
|---|---|
| Socket | AM2, AM2+, AM3, AM3+, AM4, FM1, FM2, FM2+, LGA1150, LGA1151, LGA1155, LGA1156, LGA1200, LGA2011, LGA2066 |
| Model | MAM-D6PN-120PA-R1 |
| Series | MasterAir |
| Fan Mttf | 160,000 Hours |
| Fan Speed | 650-2000 RPM (PWM) ± 10% |
| Cooler Type | Air Cooler |
| Fan Airflow | 57.3 CFM (Max) |
| Fan Quantity | 1 PCS |
| Fan Dimensions | 120 x 120 x 25 mm / 4.7 x 4.7 x 1 inch |
| Fan Noise Level | 8 – 30 dBA |
| Fan Air Pressure | 2.0 mmH2O (Max) |
| Fan Rated Current | 0.16A |
| Fan Rated Voltage | 12V DC |
| Fan Safety Current | 0.37A |
| Heat Sink Material | 6 Heat Pipes, Aluminum Fins |
| Fan Power Connector | 4-Pin (PWM) |
| Fan Power Consumption | 1.92W |
| Dimensions (L X W X H) | 135 x 125 x 165 mm / 5.3 x 4.9 x 6.5 inch |
