Cooler Master MasterFrame 500 Mesh ARGB E-ATX Mid Tower Case

The Cooler Master MasterFrame 500 Mesh ARGB (SKU: MF500M-KHNN-S01) is an open-frame mid-tower chassis designed for builders and modders who demand flexibility, strong airflow, and extensive cooling headroom. Anchored by Cooler Master’s FreeForm 2.0 Exo-structure philosophy, the exposed skeletal frame provides adaptable configuration options and access to modular design files, giving makers a true blank canvas for custom builds. Motherboard compatibility spans Mini-ITX, Mini-DTX, Micro-ATX, ATX, E-ATX, and SSI-CEB (the latter two with conditional support), making it future-proof for high-core-count workstation and gaming platforms alike. The front panel is equipped with a USB 3.2 Gen 2×2 Type-C port, a USB 3.2 Gen 1 Type-A port, and a 3.5mm headset jack — a practical I/O complement for modern peripherals. Out of the box, three preinstalled fans get your airflow moving immediately: two SickleFlow 200mm ARGB fans at the front and one 120mm ARGB fan at the rear. When you’re ready to expand, the case supports up to ten fans in total across the front, top, bottom, and rear positions, accommodating sizes from 120mm to 200mm. Radiator support is equally generous, with front and top positions each accepting up to a 360mm radiator, and the rear accepting a 120mm unit — ideal for high-performance liquid cooling loops. GPU sag is addressed with an included GPU support bracket, keeping your graphics card secure during extended gaming or compute sessions. A tool-free side panel removal system simplifies access for upgrades and cable management adjustments. The chassis accepts GPUs up to 390mm in length, ATX power supplies up to 235mm, and CPU coolers up to 190mm tall. Storage options include one combo 3.5″/2.5″ drive bay at the bottom and support for up to two 2.5″ SSDs, catering to streamlined, SSD-focused builds. The black steel and aluminum frame with tempered glass panel keeps the aesthetic clean while the ARGB lighting provides visual flair. Verifiable Specifications: – Form Factor: Mid-Tower | Motherboard: Mini-ITX / Mini-DTX / Micro-ATX / ATX / E-ATX* / SSI-CEB* (*Conditional) – Dimensions (incl. protrusions): 471 x 261 x 544mm – Preinstalled Fans: 2x SickleFlow 200mm ARGB (front) + 1x 120mm ARGB (rear) – Max Fan Support: 10 | Max Radiator: 360mm (front & top) – Max GPU Length: 390mm | Max CPU Cooler Height: 190mm | Max PSU Length: 235mm – Expansion Slots: 8 | Drive Bays: 1x 3.5″/2.5″ combo; up to 2x 2.5″ SSD – Front I/O: USB 3.2 Gen 2×2 Type-C, USB 3.2 Gen 1 Type-A, 3.5mm jack – Material: Steel, Aluminum, Tempered Glass | Color: Black | Warranty: 2 Years
