Cooler Master MasterLiquid Atmos II Pixel LED 360mm ARGB CPU Liquid Cooler

The Cooler Master MasterLiquid Atmos II Pixel LED 360mm ARGB CPU Liquid Cooler (SKU: MLX-D36M-A25SZ-P1) is a high-performance all-in-one liquid cooler designed for enthusiast builders who want both effective thermal management and expressive system aesthetics. At its heart is a patented dual-chamber pump that increases water pressure and directs optimised flow to the CPU hot spot, helping maintain stable temperatures even under sustained workloads. The pump housing is engineered using PPS (polyphenylene sulfide) reinforced with fibreglass, delivering resistance to heat and mechanical stress. The assembly process is fully automated with recorded production history, and the pump carries a rated mean time to failure (MTTF) of over 210,000 hours. It has been validated at 70 °C for 3,000 hours and 120 °C for 12 hours under controlled testing conditions. Three pre-installed 120 mm SickleFlow Edge ARGB fans deliver a combined airflow of 190 CFM (322.8 m³/h) at up to 3.61 mmH₂O static pressure. Loop Dynamic Bearing fan technology keeps vibration low, with a peak noise level of 38.5 dB(A). The fans connect via a 7-pin PWM + ARGB header and operate at 12 VDC. The Pixel LED panel — measuring 85 × 79.2 × 16 mm — features a 28 × 26 pixel (556 px total) addressable display, orientation-adjustable through the MasterCTRL software, and connects to the motherboard via a USB Type-C to 9-pin adapter. It runs on 5 VDC at up to 0.5 A rated current. The ultra-low-profile pump head (92.5 × 87 × 38.5 mm) fits cases of varying widths, while the aluminium radiator measures 394 × 119.2 × 27 mm with 400 mm tube length. A quick-mount kit supports a wide range of current Intel and AMD sockets. Dedicated offset mounting brackets for LGA 1851 are included to account for platform-specific CPU hot-spot positioning. Verified Specifications: • Radiator: Aluminium, 394 × 119.2 × 27 mm • Fans: 3× 120 mm SickleFlow Edge ARGB, up to 190 CFM, 38.5 dB(A) max • Pump Speed: 3,400 ± 300 RPM | Pump MTTF: >210,000 hours | Pump Noise: 25 dBA max • Pump Power: 3.84 W | Fan Power: 6 W | Pixel LED Power: 2 W • Pixel LED Resolution: 28 × 26 px (556 px) | Connector: USB Type-C to 9-pin • Socket Support — Intel: LGA 1851 / 1700 / 1200 / 1150 / 1151 / 1155 / 1156; AMD: AM5 / AM4 • Warranty: 6 Years
