COOLER MASTER Qube 500 Flatpack Mesh EATX Mid Tower Cabinet (White)

The Cooler Master Qube 500 Flatpack Mesh (Model: Q500-WGNN-S00) is a white E-ATX mid-tower PC cabinet that ships flat-packed and assembles using step- step instructions included in the box. Its fully modular panel system lets you remove, reposition, or swap every outer panel independently, simplifying both the initial build and long-term maintenance. The handlebar can be mounted on any corner of the chassis, and the case can even be configured in mirror or testbench orientation, giving builders an unusual degree of layout flexibility. Despite a compact internal volume of 33.44 litres (excluding protrusions), the Qube 500 Flatpack Mesh accommodates motherboards from Mini-ITX up to E-ATX (up to 296 mm wide with an SFX PSU, or up to 273 mm wide with an ATX PSU). Graphics cards up to 365 mm long fit without modification, and a built-in vertical GPU bracket is included so you can display your GPU through the tempered glass left side panel straight out of the box — with adjustable distance to maintain airflow clearance. Cooling flexibility is a key strength. Fan mounting positions span the front (one 120/140 mm slot, or two if the PSU is bottom-mounted), top (two 120/140 mm), rear (one 120 mm), bottom (two 120/140 mm), and left side (two 120/140 mm), for a maximum of eight 120 mm fans. Radiator support is equally generous: up to 280 mm radiators are accepted at the top, bottom, and left-side positions, while the front supports up to 280 mm when the PSU is mounted at the bottom. A single 120 mm SF White PWM fan (1800 rpm) is pre-installed at the rear. CPU tower coolers up to 164–172 mm tall are supported (bracket removed for upper limit). Power supplies in SFX, SFX-L, and ATX formats are all compatible. The front I/O panel provides two USB 3.2 Gen 1 Type-A ports, one USB 3.2 Gen 2×2 Type-C port, and a 3.5 mm combo audio jack. Storage capacity reaches four 3.5-inch HDDs and three 2.5-inch SSDs. Seven expansion slots and 29–32 mm of cable routing space behind the motherboard tray complete the internal layout. Dust filters are positioned at the front, top, bottom, and right side to help keep the system clean. The case carries a 2-year manufacturer warranty. Verified Specifications • Model number: Q500-WGNN-S00 • Form factor: Mid Tower • Colour: White • Internal volume: 33.44 L (excl. protrusions) • Dimensions (incl. protrusions): 406 × 231 × 415 mm (L × W × H) • Dimensions (excl. protrusions): 380 × 231 × 381 mm • Motherboard support: ITX / Micro-ATX / ATX / E-ATX (≤296 mm w/ SFX PSU; ≤273 mm w/ ATX PSU) • GPU clearance: 365 mm • CPU cooler clearance: 164–172 mm • Expansion slots: 7 • Drive bays: 4× 3.5-inch HDD, 3× 2.5-inch SSD • Fan support: up to 8× 120 mm (front/top/rear/bottom/left-side positions) • Radiator support: up to 280 mm (top, bottom, left side, front w/ PSU at bottom) • Pre-installed fan: 1× 120 mm SF White PWM, 1800 rpm (rear) • PSU compatibility: SFX / SFX-L / ATX • I/O: 2× USB 3.2 Gen 1 Type-A, 1× USB 3.2 Gen 2×2 Type-C, 3.5 mm combo audio • Materials: Steel, plastic, tempered glass (exterior); grey TG + steel (left side panel) • Dust filters: front, top, bottom, right side • Cable routing space (behind MB tray): 29–32 mm • Warranty: 2 years
