Corsair Frame 5000D RS ARGB E-ATX Mid Tower Case

The Corsair Frame 5000D RS ARGB Mid Tower Case (CC-9011309-WW) is built around the FRAME Modular Case System — a genuinely flexible platform that lets you swap out the motherboard tray, front I/O panel, front intake panel, and PSU shroud independently as your needs evolve. The internal side panel doubles as either a cable cover for a clean cable-managed build or a fan mounting surface for additional cooling headroom, giving builders control over aesthetics and thermals in a single decision. Airflow is a central design priority. The steel front panel is perforated in a 3D Y-Pattern that reduces restriction while directing cool air into the chassis. The top of the case accommodates a 420mm radiator, while the front and side positions support up to 360mm radiators. The InfiniRail Fan Mounting System supports up to 14 × 120mm fans simultaneously, with adjustable positioning for 140mm and 200mm fans as well. Four RS140 ARGB PWM fans are included out of the box, connected via daisy-chain through a single 4-pin PWM connector and a single +5V ARGB header on a compatible motherboard — no separate controller required. The front I/O panel features four USB 3.2 Gen 1 Type-A ports and one USB 3.2 Gen 2 Type-C port, with the ports repositioned to the bottom of the front panel for convenient desk-level access. The case is explicitly validated for reverse-connector motherboards from ASUS (BTF), MSI (Project Zero), and Gigabyte (Project Stealth), with dedicated cable cutouts and tie-downs optimised for hidden-connector builds. Rotatable PCI expansion slots support vertical GPU mounting (riser cable sold separately), and a GPU Anti-sag stabilization arm is included to protect heavy graphics cards and their PCIe slots. Storage options include dual 3.5-inch hard drive trays and support for up to six 2.5-inch SSDs; trays are removable to free space for custom liquid cooling loops. A dedicated mounting pocket and additional cable hooks accommodate an iCUE LINK System Hub (sold separately) for expanded ecosystem integration. The RapidRoute 2.0 pegboard-style motherboard tray provides configurable tie-down and buckle mounting points, complemented by six cinching straps, two wire loom pairs, and multiple cable clips for interior cable management. --- Verified Specifications --- SKU: CC-9011309-WW | Color: Black | Material: Steel, Tempered Glass Form Factor Support: E-ATX, ATX, Micro-ATX, Mini-ITX Pre-installed Fans: 4 × RS140 ARGB PWM (140mm) Max Fan Support: 9 fans total Radiator Support: 420mm (top), 360mm (front/side), 280mm, 240mm, 140mm, 120mm Max GPU Length: 450mm | Max CPU Cooler Height: 175mm | Max PSU Length: 250mm Expansion Slots: 8 (rotatable for vertical GPU) Storage: 2 × 3.5-inch HDD, up to 6 × 2.5-inch SSD Front I/O: 4 × USB 3.2 Gen 1 Type-A, 1 × USB 3.2 Gen 2 Type-C, headphone, microphone Dust Filters: Front, bottom, right side, left side Warranty: 2 Years
