Corsair Frame 5000D Workstation E-ATX Mid Tower Case

The Corsair Frame 5000D Workstation is a modular mid-tower PC case engineered for demanding professional and creative workloads. Its spacious interior accommodates the widest range of motherboard form factors available — Mini-ITX, Micro-ATX, ATX, E-ATX (up to 305 mm × 277 mm), SSI-CEB, and SSI-EEB — making it equally at home as a server chassis or a high-end creative workstation. Reverse-connector motherboard designs are fully supported, giving builders maximum flexibility in cable routing and aesthetics. Multi-GPU configurations are a primary design focus. The case provides vertical clearance for up to four dual-slot graphics cards, making it well suited for GPU-intensive workflows such as 3D rendering, computer-aided design, and AI model training. Up to 11 expansion slots (8 horizontal + 3 vertical) provide connection density for demanding hardware arrays, while GPU immobilisation and anti-sag hardware keep cards securely seated. A vertical GPU mount is supported, though the riser card is sold separately. Cooling flexibility is exceptional. Three pre-installed fans — two 200 mm intake fans at the front and one 140 mm exhaust fan at the rear — provide quiet, high-volume airflow out of the box. The chassis supports up to 14 additional fans across all surfaces (120 mm or 140 mm compatible). Liquid cooling is equally well catered for: the roof accepts radiators up to 420 mm, the front up to 360 mm, the side up to 360 mm, and the rear up to 140 mm, allowing dual-radiator custom loop installations. Storage is generous, with two combo HDD/SSD trays (supporting 3.5-inch drives) and two dedicated 2.5-inch SSD trays — enabling up to two 3.5-inch HDDs and up to six 2.5-inch SSDs alongside M.2 drives on the motherboard. Cable management is aided by 42 mm of routing space behind the motherboard tray and Corsair's RapidRoute system. The left side panel is tempered glass for a clear view of the build; the right panel is steel with embedded sound-dampening material for quieter operation. Verified Specifications: - Dimensions: 542 mm (H) × 556 mm (L) × 250 mm (W) - Motherboard support: Mini-ITX, Micro-ATX, ATX, E-ATX (305 × 277 mm), SSI-CEB, SSI-EEB - Expansion slots: 8 horizontal + 3 vertical - Max GPU length: 450 mm - Max CPU cooler height: 175 mm - Pre-installed fans: 3 (2× 200 mm intake, 1× 140 mm exhaust) - Total fan support: up to 14 fans (120 mm/140 mm) - Radiator support — Top: 420/360/280/240 mm; Front: 360/280/240 mm; Side: 360/280/240 mm; Rear: 140/120 mm - Drive bays: 2× 3.5-inch HDD, up to 6× 2.5-inch SSD - Front I/O: 1× USB 3.2 Gen 2×2 Type-C, 1× USB 3.2 Gen 1 (20-pin internal), HD Audio - Left panel: Tempered glass; Right panel: Steel with sound dampening - Cable routing space: 42 mm - Colour: Black - Warranty: 2 Years - SKU: CC-9011330-WW
