DeepCool AG620 G2 ARGB Dual Tower 120mm CPU Air Cooler

The DeepCool AG620 G2 ARGB is a second-generation dual-tower CPU air cooler engineered for enthusiasts who demand strong thermal performance without the complexity or cost of liquid cooling. At its core are six 6 mm copper heat pipes that run through a dense nickel-plated coldplate, drawing heat away from the CPU IHS and dispersing it across two independent fin stacks. DeepCool calls this arrangement Core Touch Technology 2.0 (CTT 2.0), an optimised pipe layout designed to maximise contact area and thermal transfer efficiency compared to the first-generation AG620. Two 120 mm closed-wheel ARGB PWM fans are mounted in a push-pull configuration between and around the towers. The reinforced blade structure reduces lateral air leakage, channelling airflow directly through the fin stacks for more focused cooling. Each fan is independently controlled via a 4-pin PWM connector, so the system can ramp speed in proportion to actual CPU load. The addressable RGB lighting connects through a standard 3-pin (+5V-D-G) header, making it compatible with major motherboard ARGB ecosystems. The heatsink features a refined matrix fin stack design capped with a decorative top cover, giving the cooler a premium appearance inside windowed cases. The overall product footprint is 129 × 136 × 159 mm (L × W × H), so users should verify clearance against their case's CPU cooler height limit before purchasing. Socket compatibility covers a broad range of current and recent platforms: Intel LGA1851, LGA1700, LGA1200, LGA1151, LGA1155, and LGA1150, as well as AMD AM5 and AM4. The bundled mounting hardware is designed for straightforward installation with even pressure across the IHS, and the cooler carries a 3-year manufacturer warranty. Verified Specifications: • Product dimensions: 129 × 136 × 159 mm (L × W × H) • Heatsink dimensions: 127 × 110 × 156 mm (L × W × H) • Heat pipes: 6 × 6 mm diameter • Fan dimensions: 120 × 120 × 25 mm • Fan speed: 500–2000 ±10% RPM (inner) / 500–2200 ±10% RPM (outer) • Fan airflow: 62.16 CFM / 68.85 CFM • Fan static pressure: 1.75 mmAq / 2.10 mmAq • Fan noise: ≤28.10 dB(A) / ≤30.93 dB(A) • Fan connector: 4-pin PWM • Bearing type: Hydro Bearing • Fan rated voltage: 12 VDC • Fan rated current: 0.15 A / 0.18 A • Fan power consumption: 1.8 W / 2.16 W • LED type: Addressable RGB (ARGB) • LED connector: 3-pin (+5V-D-G) • LED rated voltage: 5 VDC • LED power consumption: 1.70 W • Socket support: LGA1851, LGA1700, LGA1200, LGA1151, LGA1155, LGA1150, AM5, AM4 • Warranty: 3 years
