DeepCool AK700 Digital NYX 120mm Single-Tower CPU Air Cooler

The DeepCool AK700 Digital NYX is a high-performance single-tower CPU air cooler designed for enthusiasts and power users who demand both effective thermal management and real-time system monitoring without switching to an all-in-one liquid cooler. It builds on the established AK DIGITAL series by combining refined engineering with a standout quad-segmented digital display, giving builders a practical and visually distinct cooling solution. At the core of the AK700 Digital NYX is DeepCool’s Core Touch Technology 2.0 (CTT 2.0), which focuses on maximising contact between the precision-machined copper base and the CPU integrated heat spreader. Seven 6 mm copper heat pipes thread through a dense single-tower fin array, efficiently moving heat away from the processor and dissipating it across the heatsink’s matrix fin layout. The overall product dimensions measure 126 × 98 × 157 mm, while the heatsink itself measures 124 × 76 × 151 mm, keeping the footprint relatively compact for a high-end air cooler. The included 120 × 120 × 25 mm fan uses a hydraulic bearing and a three-phase, six-slot, four-pole motor for smooth, long-lasting operation. It spins up to 2,700 ± 10% RPM and moves up to 77.23 CFM of airflow at a static pressure of 5.13 mmAq. Noise levels are rated at 21.0 dB(A) at low speeds, 28.8 dB(A) at mid speeds, and 36.0 dB(A) at maximum speed. The 4-pin PWM connector allows the motherboard or DeepCreative software to modulate fan speed automatically via an AI-driven algorithm that tracks CPU load in real time. The quad-segmented digital display module (29 × 39 mm) can show CPU temperature, usage percentage, wattage, and frequency simultaneously. It draws just 0.65 W at 5 VDC and requires a single open USB 2.0 internal header for data and power. Offset heat pipes keep the heatsink positioned away from the first DRAM slot, preserving compatibility with tall memory heat spreaders. Offset mounting hardware accommodates Intel LGA1851, LGA1700, LGA1200, LGA1151, LGA1150, and LGA1155 sockets, as well as AMD AM5 and AM4 platforms. Net weight is 1,252 g. A 3-year warranty is included. Verified Specifications: – Product dimensions: 126 × 98 × 157 mm (L × W × H) – Heatsink dimensions: 124 × 76 × 151 mm (L × W × H) – Net weight: 1,252 g – Heat pipes: 6 mm diameter × 7 pcs, copper – Fan dimensions: 120 × 120 × 25 mm – Max fan speed: 2,700 ± 10% RPM – Fan airflow: 77.23 CFM – Fan static pressure: 5.13 mmAq – Fan noise: 21.0 / 28.8 / 36.0 dB(A) – Fan connector: 4-pin PWM – Bearing type: Hydro Bearing – Fan rated voltage: 12 VDC, 0.35 A, 4.2 W – Display area: 29 × 39 mm – Display module: 5 VDC, 0.13 A ± 10%, 0.65 W – Socket support: Intel LGA1851/1700/1200/1151/1150/1155; AMD AM5/AM4 – Warranty: 3 years
