DEEPCOOL AN600 Single Tower 120mm CPU Air Cooler ( Black )

The Deepcool AN600 is a purpose-built low-profile CPU air cooler designed for compact Small Form Factor (SFF) and Mini-ITX systems where vertical clearance is a premium constraint. Standing at just 67mm tall with overall product dimensions of 122×120×67mm, the AN600 manages to deliver a rated thermal design power (TDP) of 180W — a figure that places it well above many competing low-profile solutions. At the core of the AN600's thermal performance are six optimised 6mm copper heatpipes that efficiently transfer heat away from the raised copper coldplate and through an array of 62 aluminium fins. This combination maximises surface area while keeping the heatsink dimensions to 121×120×52mm. The included 120×120×15mm slim fan features Fluid Dynamic Bearing (FDB) technology, ensuring long-term reliability and whisper-quiet operation. The fan operates across a speed range of 500 to 1,850 RPM (±10%) via a 4-pin PWM connector, delivering up to 61.56 CFM of airflow at a maximum static pressure of 1.97 mmAq. At peak, fan noise stays at or below 24.4 dB(A). A bundled low-noise adapter cable (LSP) further reduces the operating ceiling to 500–1,250 RPM, lowering airflow to 41.51 CFM and capping noise at or below 20 dB(A) — a meaningful benefit for home theatre or near-silent PC builds. The AN600's top-down airflow direction is a deliberate design choice: air is pushed downward through the fin stack and directly over the RAM slots and VRM area of the motherboard, providing secondary cooling to components that typically run hotter in cramped enclosures. With 40mm of RAM clearance, the AN600 is compatible with standard-height and many mid-height memory modules. Installation is straightforward thanks to an all-metal backplate that distributes mounting pressure evenly behind the CPU socket. Socket compatibility spans Intel LGA1700, LGA1200, LGA1151, LGA1150, and LGA1155, as well as AMD AM5 and AM4 platforms. Subtle white LED lighting adds visual character without overwhelming the build aesthetic. The AN600 carries a 3-year manufacturer warranty and weighs 628g. Verified Specifications: - Model: AN600 | P/N: R-AN600-BKNNMN-G - Product Dimensions: 122×120×67mm (L×W×H) - Heatsink Dimensions: 121×120×52mm - Net Weight: 628g - Heatpipes: ø6mm × 6 - Fan Dimensions: 120×120×15mm - Fan Speed: 500–1,850 RPM ±10% (PWM) | With LSP: 500–1,250 RPM ±10% - Fan Airflow: 61.56 CFM | With LSP: 41.51 CFM - Fan Air Pressure: 1.97 mmAq | With LSP: 1.19 mmAq - Fan Noise: ≤24.4 dB(A) | With LSP: ≤20 dB(A) - Fan Connector: 4-pin PWM | Bearing: Fluid Dynamic Bearing - Fan Rated Voltage: 12 VDC | Current: 0.27A | Power: 3.24W - LED: White LED - Socket Support: Intel LGA1700/1200/1151/1150/1155 | AMD AM5/AM4 - Warranty: 3 Years
