Deepcool CC560 Limited V2 ATX Mid Tower Case

The DEEPCOOL CC560 Limited V2 is a well-appointed ATX mid-tower chassis designed for builders who want wide component compatibility without compromising on airflow or storage flexibility. Its full-sized tempered glass side panel gives a clear view of the system interior, while the reinforced chassis construction adds durability over previous generations. Airflow is a core priority in the CC560 Limited V2. The case features a ventilated front intake panel, a large mesh top exhaust panel with a removable magnetic dust filter, and optional fan mounting on the PSU shroud floor. This multi-zone airflow design helps move heat away from the GPU and power supply areas efficiently. The case ships without pre-installed fans, making it an ideal canvas for builders who prefer to select their own cooling solution. It supports up to three 120mm or three 140mm fans at the front, two 120mm or two 140mm fans on the top, one 120mm fan at the rear, and two additional 120mm fans on the PSU shroud — totalling up to eight 120mm or five 140mm fans across all positions. For liquid cooling enthusiasts, the CC560 Limited V2 accommodates a 360mm or 280mm radiator at the front and a 240mm radiator on top, making it compatible with a wide range of all-in-one liquid coolers available in the DEEPCOOL lineup and beyond. Component clearances are generous. CPU coolers up to 165mm tall fit without issue, discrete GPUs up to 370mm in length are supported, and ATX PS2 power supplies up to 170mm long can be installed. Motherboard compatibility spans Mini-ITX, Micro-ATX, and ATX form factors, with seven expansion slots available. Storage options include two 3.5-inch HDD bays and two dedicated 2.5-inch SSD mounts, with an additional 2.5-inch drive position available by repurposing one of the HDD bays for a third SSD. The front I/O panel provides a USB 3.0 port, a USB 2.0 port, and a combo audio jack for convenient desktop connectivity. Cable management is aided by 20mm of space behind the motherboard tray, keeping the visible interior tidy. Verified Specifications: - Model: CC560 Limited V2 | P/N: R-CC560-BKNAA0-G-2 - Dimensions: 432 × 215 × 483 mm (L × W × H) - Net Weight: 7 kg - Materials: ABS, SPCC steel, Tempered Glass - Motherboard Support: Mini-ITX / Micro-ATX / ATX - Fan Support: Front 3×120/3×140mm | Top 2×120/2×140mm | Rear 1×120mm | PSU Shroud 2×120mm - Radiator Support: Front 360/280/240/140/120mm | Top 240/140/120mm | Rear 120mm - CPU Cooler Height Limit: 165mm - GPU Length Limit: 370mm - PSU Type: ATX PS2, max 170mm - Drive Bays: 2×3.5-inch HDD, 2+1×2.5-inch SSD - Expansion Slots: 7 - Front I/O: USB 3.0 ×1, USB 2.0 ×1, Audio ×1 - Dust Filter: Magnetic top filter - Pre-Installed Fans: None - Warranty: 1 Year
