DEEPCOOL Gamer Strom PN1000M 1000W 80 Plus Gold Fully Modular ATX 3.1 Power Supply

The Deepcool Gamer Storm PN1000M is a 1000W fully modular ATX 3.1 power supply designed for high-performance gaming and workstation builds. It carries an 80 Plus Gold certification, meaning it meets stringent efficiency requirements across a broad range of typical loads. Each unit is also independently rated Gold by Cybenetics, providing an additional layer of verified efficiency assurance. At the heart of the PN1000M is a primary Japanese electrolytic capacitor, an active Power Factor Correction (PFC) circuit, a half-bridge SRC LLC topology, and DC-to-DC voltage regulation. This combination maintains a hold-up time of 16 ms or more at 80% load, helping protect connected components during brief power interruptions or fluctuations. The unit can also supply twice its rated system power output for up to 0.1 ms to manage random power spikes, ensuring stability for both current and next-generation PC platforms. For modern GPU support, the PN1000M includes a high-grade 12V-2x6 cable built from 105°C-rated 16AWG copper-core wire, capable of delivering up to 600W to a single graphics card in compliance with the PCI-E 5.1 standard. Cable management is simplified by the fully modular design — only the cables you need are connected, reducing clutter and improving airflow inside the chassis. All cables ship pre-sleeved, contributing to a clean, premium look straight out of the box. Cooling is handled by a 135mm Fluid Dynamic Bearing (FDB) fan that adjusts its speed automatically based on internal thermal conditions, helping balance noise and airflow. The PN1000M measures 150 × 150 × 86 mm, making it compatible with most standard ATX cases. It is rated for operation at altitudes up to 5,000 metres above sea level. A comprehensive protection suite covers Over Power Protection (OPP), Over Voltage Protection (OVP), Short Circuit Protection (SCP), Over Temperature Protection (OTP), Over Current Protection (OCP), Under Voltage Protection (UVP), No-Load Operation (NLO), and Surge & Inrush Protection (SIP). Verified Specifications: • Wattage: 1,000W • Efficiency: 80 Plus Gold; Cybenetics Gold • ATX Standard: ATX 3.1 • Form Factor: Fully Modular • Fan: 135mm FDB • PCIe Connectors (6+2-pin): 3 • 12V-2x6 Cable: 16AWG, 105°C rated, up to 600W • SATA Connectors: 8 • Peripheral (4-pin) Connectors: 2 • Dimensions: 150 × 150 × 86 mm • Colour: Black • Warranty: 10 Years • Series: PN-M Series • SKU: R-PNA00M-FC0B-JGIN
