DEEPCOOL GamerStorm PN650D 650W 80+ Gold ATX 3.1 Non Modular Power Supply

The Deepcool GamerStorm PN650D is a 650-watt ATX 3.1 non-modular power supply designed for mid-range gaming and content-creation builds that demand reliable, efficient power delivery. Carrying the 80 Plus Gold efficiency certification, the PN650D achieves at least 90% efficiency under a typical 50% load, reducing wasted heat inside your case and keeping electricity costs in check. Deepcool has also had each unit rated Gold by Cybenetics, providing an independent second verification of its efficiency claims. At the heart of the PN650D is an Active PFC combined with a Full-Bridge SRC LLC and a DC-to-DC conversion topology. This combination ensures clean, stable power rails and maintains a hold-up time of 16 ms or greater at 80% load — well above the industry-standard 17 ms threshold for ATX compliance, helping protect your components during brief power-line disturbances. For modern GPU support, the PN650D ships with a 16AWG copper-core sleeved 12V-2×6 (16-pin) cable capable of delivering up to 450W to PCIe 5.1-compatible graphics cards. All cables are pre-sleeved from the factory, contributing to a cleaner build aesthetic without additional cost. Cooling is handled by a 120mm Hydro Bearing fan that dynamically adjusts its speed in response to thermal load. Hydro bearing designs are noted for lower noise at light loads and longer operational life compared to sleeve-bearing alternatives. The unit is rated for continuous operation between 0 °C and 40 °C and has been qualified to function at altitudes up to 5,000 metres above sea level. Protection circuits include OPP, OVP, SCP, OTP, OCP, UVP, SIP, and NLO — covering the full range of over-power, over-voltage, short-circuit, thermal, over-current, under-voltage, surge, and no-load conditions. Regulatory approvals span CE, FCC, CCC, cTUVus, RCM, EAC, BIS, and TUV-RH, making it compliant for sale across multiple global markets including India. Verified Specifications: • Model: R-PN650D-FC0B-JGIN-V2 • Rated Output: 650W • ATX Standard: ATX12V V3.1 • Efficiency Certification: 80 Plus Gold; Cybenetics Gold • Efficiency: ≥90% at 50% load • Topology: Active PFC + Full-Bridge SRC LLC + DC-to-DC • Hold-Up Time: ≥16 ms at 80% load • Power Good Signal: 100–150 ms • Fan: 120mm Hydro Bearing, dynamic speed control • Cables: (20+4)-pin ATX ×1, (4+4)-pin CPU ×2, (6+2)-pin PCIe ×1 single / ×2 on one cable, 12V-2×6 16-pin ×1, SATA ×3 + 4-pin peripheral ×1 (×2 cables) • Protection: OPP/OVP/SCP/OTP/OCP/UVP/SIP/NLO • Operating Temperature: 0–40 °C • Altitude Rating: up to 5,000 m • Dimensions: 150 × 140 × 86 mm (W × L × H) • MTBF: 100,000 hours • Warranty: 10 years • Regulatory: CE/FCC/CCC/cTUVus/RCM/EAC/BIS/TUV-RH • Compliance: ErP 2014, WEEE, RoHS, Prop 65
