Deepcool LM360 ARGB CPU Liquid Cooler
MPN R-LM360-BKDMMC-1 · Brand DEEPCOOL
The Deepcool LM360 is a 360mm ARGB AIO liquid cooler featuring a 2.4-inch IPS LCD display with 320×240 resolution, a Gen 6 PWM pump running 2,500–3,600 RPM, three 120mm FL12 SE fans, and a 5-year warranty with support for Intel LGA1851/1700 and AMD AM5/AM4 platforms
Inclusive of GST · GST invoice available
Overview
The Deepcool LM360 is a 360mm all-in-one CPU liquid cooler that combines capable thermal management with a built-in visual display, making it a strong choice for enthusiast and high-performance desktop builds. At the heart of the cooler sits a 2.4-inch IPS LCD panel running at 320×240 resolution. The display supports MP4 video playback alongside real-time system metrics such as CPU temperature, power consumption, and memory usage — all managed through Deepcool's DeepCreative software. Screen brightness and display orientation are both adjustable via the software, and a Zen Mode option removes screen distractions for focused workloads. Cooling is handled by Deepcool's 6th-generation pump, a 3-phase, 6-slot, 4-pole motor with Field-Oriented Control (FOC) that operates between 2,500 and 3,600 RPM. This design is engineered for thermal efficiency and reduced acoustic output compared to earlier pump generations. Three 120mm FL12 SE fans with ARGB lighting and PWM speed control circulate air through the aluminium radiator. The fans use hydraulic bearings for long-term reliability, and their ARGB lighting can be synchronised with other system components. DeepCool's patented Anti-Leak Technology integrates a pressure-balancing valve into the cooling loop. The valve releases excess internal pressure when it rises above ambient levels, reducing leak risk and supporting long-term operational stability. Installation hardware for both Intel and AMD platforms is included in the box, covering LGA1851, LGA1700, LGA1200, LGA1151, LGA1150, and LGA1155 sockets on the Intel side, plus AM5 and AM4 for AMD. Compatible CPU families include Intel Core i3 through i9, Core Ultra 5/7/9, and AMD Ryzen 3 through Ryzen 9. Verifiable Specifications: • Radiator size: 360mm • Fan size: 120mm (×3, FL12 SE) • Fan connector: 4-pin PWM • Pump speed: 2,500–3,600 RPM • Pump motor: 3-phase, 6-slot, 4-pole with FOC control • LCD: 2.4-inch IPS, 320×240 resolution • Lighting: ARGB • Socket support: Intel LGA1851/1700/1200/1151/1150/1155; AMD AM5/AM4 • Warranty: 5 years • SKU: R-LM360-BKDMMC-1
Datasheet
| Warranty | 5 Years |
|---|---|
| Note*** | Features, Price and Specifications are subject to change without notice. Images use for Representation Purpose Only |
| Fan Size | 120 mm |
| Lighting | ARGB |
| Cooling Type | LIQUID AIO COOLER |
| Radiator Size | 360 mm |
| Pwm Controller | YES |
| Socket Support | LGA1700,LGA1851,LGA1200,LGA1151,LGA1150,LGA1155,AM5,AM4 |
| Supported Cooler CPU Wise | intel i3,intel i5,intel i7,intel i9,Core ultra 5,Core ultra 7,Core ultra 9,AMD Ryzen 3,AMD Ryzen 5,AMD Ryzen 7,AMD Ryzen 9 |
