Features of FRACTAL DESIGN Lumen S24 V2 240mm Liquid CPU Cooler (Black)
The right way up
– The removable top can be turned at 90-degree intervals, making the logotype horizontal independent of the mounting orientation
– Low-permeability rubber tubes with braided nylon sleeves
From subtle to stunning
– Duality design provides both a stealthy and illuminated look, controlled from your motherboard RGB UI
– Six ARGB LEDs are yours to command via your motherboard or controller
Powerful aspects
Aspect fans for low turbulence and chaining support
Forget the thermal paste
– Thermal paste is pre-applied to ensure a proper and pain-free installation
– Articulating elbow fittings make tubes easier to route and reduces tension on the cold plate housing
Common denominators
– Compatible with LGA 1700 and AM5
– Supports the most common sockets for both Intel and AMD
Color-coordinate your cooling
Compatible with ASUS AURA, Gigabyte Fusion, MSI Mystic Light, ASRock Polychrome and Razer Chroma
Specifications of FRACTAL DESIGN Lumen S24 V2 240mm Liquid CPU Cooler (Black)
| Suitable location: | Processor |
| Type: | All-in-one liquid cooler |
| Fan diameter: | 12 cm |
| Supported processor sockets: | LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 1200 (Socket H5), LGA 1366 (Socket B), LGA 1700, LGA 2011 (Socket R), LGA 2011-v3 (Socket R), LGA 2066, Socket AM2, Socket AM2+, Socket AM3, Socket AM3+, Socket AM4, Socket AM5, Socket FM1, Socket FM2, Socket FM2+ |
| Rotational speed (min): | 500 RPM |
| Rotational speed (max): | 2000 RPM |
| Noise level (low speed): | 10 dB |
| Noise level (high speed): | 33.2 dB |
| Minimum airflow (imperial): | 13 cfm |
| Maximum airflow: | 56 cfm |
| Minimum air pressure: | 0.23 mmH2O |
| Maximum air pressure: | 2.34 mmH2O |
| Pulse-width modulation (PWM) support: | |
| Pump noise level: | 22 dB |
| Fan bearing technology: | Rifle bearing |
| Pump bearing technology: | Ceramic bearing |
| Quantity per pack: | 1 pc(s) |
| Pump motor speed: | 4000 RPM |
| Pump’s mean time to failure (MTTF): | 50000 h |
| Fan’s mean time to failure (MTTF): | 90000 h |
| Design | |
| Product colour: | Black |
| Radiator material: | Aluminum |
| Base plate material: | Copper |
| Number of fans: | 2 fan(s) |
| Fins material: | Aluminium |
| Illumination LED: | |
| Number of LEDs: | 6 |
| Illumination colour: | Multi |
| Power | |
| Pump voltage: | 12 V |
| Pump current: | 340 mA |
| Fan voltage: | 12 V |
| Fan current: | 0.37 A |
| Weight & dimensions | |
| Radiator width: | 12 cm |
| Radiator depth: | 27.2 cm |
| Radiator height: | 2.7 cm |
| Tube length: | 40 cm |
| Package width: | 137 mm |
| Package depth: | 332 mm |
| Package height: | 205 mm |
| Package weight: | 1.77 kg |
