Fractal Design Meshify 3 Ambience Pro RGB White E-ATX Mid Tower Case
MPN FD-C-MES3A-05 · Brand FRACTAL DESIGN · ATX, E-ATX, mATX, Mini-ITX
The Fractal Design Meshify 3 Ambience Pro RGB White (FD-C-MES3A-05) is an E-ATX mid-tower case with three pre-installed Momentum 14 fans, 360 mm front radiator support, and a 20 Gbps USB-C top I/O panel
Inclusive of GST · GST invoice available
Overview
The Fractal Design Meshify 3 Ambience Pro RGB (SKU: FD-C-MES3A-05) is a white E-ATX mid-tower case built around strong airflow fundamentals and a clean aesthetic. Its rockface-inspired mesh front panel promotes unrestricted air intake while the steel and tempered glass construction delivers a premium finish that suits a wide range of builds. Three pre-installed Momentum 14 fans with LCP (liquid crystal polymer) blades and true fluid dynamic bearings (FDB) get your cooling setup running from day one. An integrated air guide directs airflow toward the GPU mounting zone to help manage thermal output from long graphics cards. The case supports graphics cards up to 349 mm in length, so high-end single-slot and dual-slot AIB coolers fit comfortably. Cooling flexibility extends further with front radiator support up to 360 mm and top radiator support up to 280 mm, plus a 120 mm rear radiator position. Total fan mounts accommodate up to six 120 mm units or a combination of five 140 mm and one 120 mm fans. Removable radiator brackets simplify installation and maintenance. Motherboard compatibility spans E-ATX (up to 277 mm wide), ATX, Micro-ATX, and Mini-ITX form factors, giving builders considerable flexibility. Cable management is supported by a cable cover and new cable aligners, while a sliding top panel with a fabric pull tab makes panel removal straightforward. Panels are designed for tool-friendly, easy removal throughout. The top I/O panel includes a 20 Gbps USB Type-C port, two USB-A 5 Gbps ports, a combined audio jack, and a power button. RGB lighting and fan behaviour can be configured through the included Adjust Pro Hub using a download-free tool. Verified Specifications: - Form Factor: E-ATX (up to 277 mm), ATX, Micro-ATX, Mini-ITX - Material: Steel, Tempered Glass (TG Clear Tint) - Colour: White - Pre-installed Fans: 3 × Momentum 14 (140 mm, FDB, LCP blades) - Max Fan Support: 6 total (6 × 120 mm or 5 × 140 mm + 1 × 120 mm) - Fan Positions: Front 3 × 120 mm / 3 × 140 mm; Top 2 × 120 mm / 2 × 140 mm; Rear 1 × 120 mm - Radiator Support: Front 280/360 mm; Top 240/280 mm; Rear 120 mm - Max GPU Length: 349 mm - Max CPU Cooler Height: 173 mm - Max PSU Length: 180 mm - Expansion Slots: 7 - Storage: 4 × 2.5" SSD, 2 × 3.5" HDD - Dust Filters: Bottom - I/O: USB Type-C 20 Gbps, 2 × USB-A 5 Gbps, Audio Combo Jack, Power Button - Warranty: 2 Years
Datasheet
| Warranty | 2 Years |
|---|---|
| Form Factor | ATX, E-ATX, mATX, Mini-ITX |
| color | White |
| Note*** | Features, Price, Specifications are subject to change without notice. Images used for representation purposes only |
| Material | Steel, Tempered Glass |
| I/O Panel | USB Type-C 20 Gbps,USB Type-A 5 Gbps,Audio Combo Jack,Power button |
| Cabinet Size | MID-TOWER |
| Dust Filters | Bottom |
| Max 2.5" SSD | 4 |
| Max 3.5" HDD | 2 |
| Max GPU Length | 349mm |
| Max Psu Length | 180mm |
| Expansion Slots | 7 |
| Max Fan Support | 6 |
| Radiator Support | 360mm,280mm,240mm,140mm,120mm |
| Pre Installed Fans | 3 |
| Max CPU Cooler Height | 173mm |
