Fractal Design Torrent TG Light Tint (E-ATX) Mid Tower Cabinet (Black)
MPN FD-C-TOR1A-01 · Brand FRACTAL DESIGN · E-ATX, ATX, mATX, Mini-ITX
The Fractal Design Torrent TG Light Tint Black is an E-ATX mid-tower cabinet built for maximum airflow, arriving with five pre-installed PWM fans, support for 420 mm radiators, and a light-tint tempered glass side panel
Inclusive of GST · GST invoice available
Overview
The Fractal Design Torrent TG Light Tint Mid Tower Cabinet in Black (SKU: FD-C-TOR1A-01) is an E-ATX-compatible chassis engineered around maximising airflow from the moment it leaves the box. Its open-grille front panel and unobstructed internal layout work in tandem with five pre-installed fans — two 180 x 38 mm Dynamic GP-18 PWM fans at the front and three 140 mm Dynamic GP-14 PWM fans at the bottom — to deliver substantial air movement across the entire system. The 38 mm fan depth is a notable design choice: it provides additional static pressure and volume compared to standard 25 mm fans of the same diameter, making it well suited for builds that rely on heavy air cooling or supplement a custom water loop. The case supports motherboards up to E-ATX (also compatible with ATX, mATX, ITX, SSI-EEB, and SSI-CEB form factors), accommodating a wide range of high-end platform configurations. The front panel can host radiators up to 360 mm or 420 mm, including a 360 x 180 mm format, while the bottom panel supports radiators up to 420 mm (458 mm maximum length). The rear accommodates a single 120 mm or 140 mm fan or radiator. GPU clearance measures 461 mm total (423 mm with the front fan mounted), and the CPU cooler ceiling sits at 188 mm. PSU length is limited to 230 mm. Storage provisions include two dedicated 3.5-inch drive bays and four dedicated 2.5-inch SSD brackets, all included in the box. Seven bridgeless expansion slots provide flexibility for multi-GPU or high-profile add-in card setups. The front I/O panel carries one USB 3.1 Gen 2 Type-C port, two USB 3.0 ports, and HD Audio jacks. The left side panel is light-tint tempered glass with a bolt-free top-latching mechanism for tool-free access, while the right panel is steel. A pre-installed Nexus 9P Slim PWM fan hub manages all included fans. Front and bottom nylon dust filters are included. Cable routing space behind the motherboard tray measures 32 mm, with grommets and fixed cable straps provided. The PSU is housed under an aerodynamic top-mounted shroud. Verifiable specifications at a glance: • Dimensions (L×W×H): 544 × 242 × 530 mm | Net weight: 11.1 kg • Fan mounts: 7× 120/140 mm or 4× 180 mm total • Front fan mounts: 3× 120/140 mm or 2× 180 mm • Bottom fan mounts: 3× 120/140 mm or 2× 180 mm • Rear fan mount: 1× 120/140 mm • Pre-installed fans: 5 (2× 180 mm GP-18 front + 3× 140 mm GP-14 bottom) • Expansion slots: 7 (bridgeless) • Warranty: 2 years
Datasheet
| Warranty | 2 Years |
|---|---|
| Form Factor | E-ATX, ATX, mATX, Mini-ITX |
| Color | Black |
| Note*** | Features, Price and Specifications are subject to change without notice. Images use for Representation Purpose Only |
| Material | Steel, Tempered Glass |
| Rear Fan | 1x 120/140 mm |
| Front Fan | 3x 120/140 mm or 2x 180 mm (2x Dynamic GP-18 included in standard version, 2x Prisma AL-18 included in RGB version) |
| Bottom Fan | 3x 120/140 mm or 2x 180 mm (3x Dynamic GP-14 PWM included in standard version, 3x Prisma AL-14 PWM included in RGB version) |
| Net Weight | 11.1 kg except for Solid (10.4 kg) and White TG (10.8 kg) |
| Cabinet Size | MID-TOWER |
| Dust Filters | Front, Bottom |
| Gross Weight | 13.7 kg except for Solid (13 kg) and White TG (13.4 kg) |
| Max 2.5" SSD | 4 |
| Max 3.5" HDD | 2 |
| Rear Radiator | Up to 120/140 mm |
| Front Radiator | Up to 360/420 mm, including 360×180 mm |
| GPU Max Length | 461 mm total, 423 mm with front fan mounted |
| Max GPU Length | 461mm |
| Max Psu Length | 230mm |
| Psu Max Length | 230 mm |
| Bottom Radiator | Up to 360/420 mm (458 mm max length) |
| Expansion Slots | 7 |
| Front I/O Panel | USB 3.1 Gen 2 Type-C, USB 3.0, HD Audio |
| Front Interface | 1x USB 3.1 Gen 2 Type-C, 2x USB 3.0, HD Audio |
| Left Side Panel | Tempered glass |
| Max Fan Support | 7 |
| Radiator Support | 420mm,360mm,280mm,240mm,140mm,120mm |
| Right Side Panel | Steel |
| Total Fan Mounts | 7x 120/140 mm or 4x 180 mm |
| Power Supply Type | ATX |
| Fixed Cable Straps | Yes |
| Pre Installed Fans | 5 |
| Cable Routing Space | 32 mm |
| Captive Thumbscrews | HDD brackets, SSD brackets, Top panel, Bottom fan bracket |
| CPU Cooler Max Height | 188 mm |
| Max CPU Cooler Height | 188mm |
| Cable Routing Grommets | Yes |
| Tool-Less Push-To-Lock | Both side panels |
| Case Dimensions (Lxwxh) | 544 x 242 x 530 mm |
| Motherboard Compatibility | E-ATX / ATX / mATX / ITX / SSI-EEB / SSI-CEB |
| Package Dimensions (Lxwxh) | 640 x 343 x 674 mm |
| Dedicated 2.5" Drive Mounts | 4 (included) |
| Dedicated 3.5" Drive Mounts | 2 (included) |
| Case Dimensions W/O Feet/Protrusions/Screws | 525 x 242 x 495 mm |
