Gigabyte H110M-M.2 DDR4 M-ATX Motherboard
MPN H110M-M-2 · Brand GIGABYTE · mATX
The Gigabyte H110M-M.2 is a Micro-ATX motherboard with LGA1151 socket, Intel H110 chipset, support for 6th/7th Gen Intel Core processors, dual-channel DDR4 up to 32 GB, an M.2 slot, and Gigabit LAN
Inclusive of GST · GST invoice available
Overview
The Gigabyte H110M-M.2 is a Micro-ATX motherboard built on Intel's H110 chipset and the LGA1151 socket, designed to support 6th and 7th Generation Intel Core processors. It offers a reliable and compact foundation for office builds, home PCs, and small business systems that demand stability without unnecessary complexity. Memory configuration supports dual-channel DDR4 across two DIMM slots, with a maximum capacity of 32 GB and speeds up to DDR4-2400. The board accommodates ECC Un-buffered and non-ECC Un-buffered DIMM modules in 1Rx8, 2Rx8, and 1Rx16 configurations, and also supports Extreme Memory Profile (XMP) modules. Storage connectivity is a key highlight. A single M.2 Socket 3 connector supports both PCIe Gen 2 x2 and SATA modes, enabling installation of compact M.2 SSDs for fast system storage. Four additional SATA 6Gb/s connectors provide ample options for traditional drives. The expansion slot layout includes one PCIe 3.0 x16 slot for a dedicated graphics card or NVMe SSD, plus two PCIe 2.0 x1 slots for additional cards. The rear I/O panel provides a PS/2 combo port, D-Sub and HDMI 1.4 video outputs for multi-display setups, two USB 3.2 Gen 1 ports, four USB 2.0/1.1 ports, a Gigabit Ethernet RJ-45 jack, and three audio jacks backed by an 8-channel HD audio codec with Audio Noise Guard and LED trace path lighting. GIGABYTE's Glass Fabric PCB technology reduces moisture ingress for added long-term reliability, while Low RDS MOSFETs contribute to reduced heat generation. The onboard Gigabit LAN is paired with cFosSpeed Internet Accelerator software for traffic prioritisation. A Trusted Platform Module (TPM) header is also present for security applications. --- Verified Specifications --- Socket: LGA1151 | Chipset: Intel H110 | Form Factor: Micro-ATX | CPU Support: 6th & 7th Gen Intel Core | Memory: 2 x DDR4 DIMM, Dual Channel, max 32 GB, up to DDR4-2400 | Storage: 1 x M.2 (PCIe Gen2 x2 / SATA), 4 x SATA 6Gb/s | Expansion: 1 x PCIe 3.0 x16, 2 x PCIe 2.0 x1 | Video Out: 1 x HDMI 1.4, 1 x D-Sub | USB: 2 x USB 3.2 Gen 1, 4 x USB 2.0/1.1 (rear); 1 x USB 3.2 Gen 1 header, 1 x USB 2.0 header (internal) | LAN: Gigabit Ethernet | Audio: 8-channel HD, 3 x rear audio jacks | Warranty: 3 Years
Datasheet
| Memory Type | DDR4 |
|---|---|
| Warranty | 3 Years |
| Form Factor | mATX |
| Chipset | H110 |
| Socket | LGA1151 |
| CPU Type | 7th Gen,6th Gen |
| Max Memory | 32 GB |
| Memory Speed | up to 2400 |
| Platform | INTEL |
| Memory Feature | Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for Extreme Memory Profile (XMP) memory modules |
| Expansion Slots | 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x16 (PCIEX16) * The PCIEX16 slot can only support a graphics card or an NVMe SSD. 2 x PCI Express x1 slots, supporting PCIe 2.0 and running at x1 (PCIEX1_1, PCIEX1_2) |
| Channel Supported | Dual Channel |
| Back Panel I/O Ports | 1 x PS/2 keyboard/mouse port 1 x serial port 1 x D-Sub port (Note) 1 x HDMI port (Note) 2 x USB 3.2 Gen 1 ports 4 x USB 2.0/1.1 ports 1 x RJ-45 port 3 x audio jacks |
| Internal I/O Connector | 1 x 24-pin ATX main power connector 1 x 4-pin ATX 12V power connector 1 x CPU fan header 1 x system fan header 1 x M.2 Socket 3 connector 4 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x USB 3.2 Gen 1 header 1 x USB 2.0/1.1 header 1 x Trusted Platform Module (TPM) header 1 x Clear CMOS jumper |
