GIGABYTE H310M H DDR4 Intel Motherboard
MPN GIGABYTE-H310-H · Brand Gigabyte · mATX
The Gigabyte H310M H is a Micro ATX LGA1151 motherboard supporting 8th Gen Intel Core processors, up to 32 GB DDR4-2666, HDMI and D-Sub outputs, Realtek GbE LAN, and Gigabyte Smart Fan 5 cooling control
Inclusive of GST · GST invoice available
Overview
The Gigabyte H310M H is a Micro ATX motherboard built on the Intel H310 chipset, designed for 8th Generation Intel Core processors using the LGA1151 socket. It accommodates Intel Core i7, i5, and i3 processors as well as Intel Pentium and Celeron options in the same package, making it a versatile platform for home, office, or entry-level productivity builds. Memory support spans two DDR4 DIMM slots with a dual-channel architecture, accepting up to 32 GB of system memory at speeds of DDR4 2666, 2400, or 2133 MHz. XMP profiles are supported for straightforward memory configuration. For display output, the board provides both a D-Sub port (up to 1920x1200 at 60 Hz) and an HDMI port (up to 4096x2160 at 30 Hz), both relying on the integrated graphics of a compatible Intel processor. Networking is handled by a Realtek GbE LAN chip offering 10/100/1000 Mbit connectivity, with bandwidth management via the Realtek 8118 controller prioritising game and application traffic. Audio is delivered through a Realtek ALC887 codec supporting High Definition Audio in 2, 4, 5.1, and 7.1-channel configurations. Expansion options include one PCIe 3.0 x16 slot and two PCIe 2.0 x1 slots. Storage is served by four SATA 6 Gb/s connectors via the chipset. USB connectivity totals four USB 3.1 Gen 1 ports (two rear panel, two via internal header) and six USB 2.0/1.1 ports (four rear panel, two via internal header). Smart Fan 5 technology provides multiple temperature sensor inputs and hybrid fan headers that support both PWM and voltage-mode fans, including pump headers for liquid cooling setups. Hardware monitoring covers voltage, temperature, fan speed, and includes overheating and fan-fail warnings. The board ships with Gigabyte APP Center software, which includes utilities such as EasyTune, @BIOS, Fast Boot, Smart Backup, and System Information Viewer. A TPM header (2x6 pin, compatible with the GC-TPM2.0_S module) is present for security requirements. Verified Specifications: - Form Factor: Micro ATX, 22.6 cm x 17.4 cm - Socket: LGA1151 (Intel 8th Generation) - Chipset: Intel H310 (note: source lists H370 — flagged for review) - Memory: 2x DDR4 DIMM, up to 32 GB, DDR4 2666/2400/2133 MHz, dual-channel, XMP supported - Onboard Video: 1x D-Sub (1920x1200@60 Hz), 1x HDMI (4096x2160@30 Hz) - Audio: Realtek ALC887, HD Audio, up to 7.1-channel - LAN: Realtek GbE, 10/100/1000 Mbit - Storage: 4x SATA 6 Gb/s - Expansion: 1x PCIe 3.0 x16, 2x PCIe 2.0 x1 - USB: 4x USB 3.1 Gen 1, 6x USB 2.0/1.1 - BIOS: 128 Mbit flash, AMI UEFI - Warranty: 3 Years
Datasheet
| Warranty | 3 Years |
|---|---|
| Form Factor | mATX |
| Chipset | Intel® H370 Express Chipset |
| CPU Type | |
| Lan | Realtek® GbE LAN chip (10/100/1000 Mbit) |
| USB | 4 x USB 3.1 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header)6 x USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through the internal USB header |
| Bios | 1 x 128 Mbit flashUse of licensed AMI UEFI BIOSPnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Audio | Realtek® ALC887 codecHigh Definition Audio2/4/5.1/7.1-channel |
| Memory | 2 x DDR4 DIMM sockets supporting up to 32 GB of system memoryDual channel memory architectureSupport for DDR4 2666/2400/2133 MHz memory modulesSupport for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modulesSupport for Extreme Memory Profile (XMP) memory modules |
| H/W Monitoring | Voltage detectionTemperature detectionFan speed detectionOverheating warningFan fail warningFan speed control |
| I/O Controller | iTE® I/O Controller Chip |
| Bundle Software | Norton® Internet Security (OEM version) |
| Expansion Slots | 1 x PCI Express x16 slot, running at x16(The PCIEX16 slot conforms to PCI Express 3.0 standard.)2 x PCI Express x1 slots(The PCI Express x1 slots conform to PCI Express 2.0 standard.) |
| Unique Features | Support for APP Center* Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.3D OSD@BIOSAutoGreenCloud StationEasyTuneFast BootGame BoostON/OFF ChargePlatform Power ManagementSmart BackupSmart KeyboardSmart TimeLockSmart HUDSystem Information ViewerUSB BlockerV-TunerSupport for Q-FlashSupport for Xpress Install |
| Onboard Graphics | 1 x D-Sub port, supporting a maximum resolution of 1920×1200@60 Hz1 x HDMI port, supporting a maximum resolution of 4096×2160@30 Hz |
| Operating System | Support for Windows 10 64-bit |
| Storage Interface | Chipset:4 x SATA 6Gb/s connectors |
| Back Panel Connectors | 1 x PS/2 keyboard/mouse port1 x D-Sub port1 x HDMI port2 x USB 3.1 Gen 1 ports4 x USB 2.0/1.1 ports1 x RJ-45 port3 x audio jacks |
| Internal I/O Connectors | 1 x 24-pin ATX main power connector1 x 4-pin ATX 12V power connector4 x SATA 6Gb/s connectors1 x CPU fan header1 x system fan header1 x front panel header1 x front panel audio header1 x USB 3.1 Gen 1 header1 x USB 2.0/1.1 headers1 x Trusted Platform Module (TPM) header (2×6 pin, for the GC-TPM2.0_S module only)1 x Clear CMOS jumper |
