GIGABYTE Z790 Aorus Xtreme Wifi DDR5 Intel Motherboard
MPN GIGABYTE-Z790-AORUS-XTREME-DDR5 · Brand Gigabyte · E-ATX
The GIGABYTE Z790 Aorus Xtreme WiFi is an EATX motherboard for LGA1700 Intel 12th/13th Gen CPUs, featuring DDR5 support up to 128 GB, 10 GbE + 2.5 GbE dual LAN, Thunderbolt 4, and ESS high-definition audio
Inclusive of GST · GST invoice available
Overview
The GIGABYTE Z790 Aorus Xtreme WiFi is a flagship-class EATX motherboard built around the Intel Z790 chipset, designed to extract maximum performance from 12th and 13th Generation Intel Core processors using the LGA1700 socket. Its large EATX footprint (30.5 cm × 28.5 cm) accommodates a rich feature set that spans elite connectivity, high-fidelity audio, and extensive DDR5 memory support — making it a compelling platform for demanding content creators and power users alike. Memory headroom is a defining strength: four DDR5 slots support dual-channel operation with a capacity ceiling of 128 GB. Overclocked profiles extend from DDR5-5600 through DDR5-8000 (O.C.), giving builders substantial tuning latitude when paired with capable XMP/EXPO kits. Connectivity is equally comprehensive. The rear I/O carries 10 USB 3.2 Gen 2 Type-A ports, two Thunderbolt 4 connectors (USB Type-C with USB 3.2 Gen 2 signalling), and support for S/PDIF digital audio output. Internal headers include a USB Type-C port with USB 3.2 Gen 2×2 (20 Gbps) support. Network options are notably strong: a Marvell AQtion AQC107 controller delivers up to 10 GbE wired throughput (with fallback to 5G/2.5G/1G/100M), while a secondary Intel 2.5GbE port adds flexibility. board WiFi is present as indicated in the product name, though the specific WiFi standard (e.g., WiFi 6E) is not confirmed in the provided specification data. Audio is handled by an ESS ES9280AC DAC chip supplemented by two ESS ES9080 chips, outputting through two rear audio jacks with High Definition Audio support. The mic input is mono only. For video output, the board exposes the CPU's integrated graphics via the two Thunderbolt 4 ports, which also carry an Intel Thunderbolt 4 controller. Storage options include four SATA 6 Gb/s connectors for traditional drives, alongside M.2 slots (count not confirmed in source data — manual review recommended). Expansion slots comprise two PCIe x16-keyed slots operating at PCIe 3.0 x4 and x1 respectively. Power delivery uses a 24-pin ATX connector and dual 8-pin +12 V CPU connectors to support high-TDP processors. Verified Specifications: - Chipset: Intel Z790 - Socket: LGA1700 - CPU Compatibility: 12th & 13th Gen Intel Core, Pentium Gold, Celeron - Form Factor: EATX (30.5 cm × 28.5 cm) - Memory: 4 × DDR5 slots, up to 128 GB, dual-channel, DDR5-8000 O.C. - Primary LAN: Marvell AQtion AQC107 — 10 GbE/5G/2.5G/1G/100M - Secondary LAN: Intel 2.5GbE — 2.5G/1G/100M - Rear USB: 10 × USB 3.2 Gen 2 Type-A - Thunderbolt: 2 × Thunderbolt 4 (USB Type-C) rear ports - Internal USB: 1 × USB Type-C (USB 3.2 Gen 2×2) header - Audio: ESS ES9280AC + 2× ESS ES9080; 2 rear audio jacks; S/PDIF out - SATA: 4 × SATA 6 Gb/s - PCIe: 2 × PCIe x16-keyed slots (PCIe 3.0 ×4 and ×1) - Power: 1 × 24-pin + 2 × 8-pin +12 V
Datasheet
| Form Factor | E-ATX |
|---|---|
| Chipset | INTEL Z790 |
| CPU Type | 13th Gen Intel® Core™ Processors & 12th Gen Intel® Core™, Pentium® Gold and Celeron® Processors |
| USB | 10 x USB 3.2 Gen 2 Type-A ports (red) |
| Model | Z790 Aorus Xtreme |
| Power Pin | 1 x 24-pin Main Power connector, 2 x 8-pin +12V Power connectors |
| Dimensions | 30.5cm x 28.5cm |
| S/Pdif Out | Support for S/PDIF Out |
| Sata 3Gb/S | 4 x SATA 6Gb/s connectors |
| Audio Ports | 2 x audio jacks, The mic in jack supports only mono microphone input |
| Onboard USB | 1 x USB Type-C® port with USB 3.2 Gen 2×2 support, available through the internal USB header, 6 x USB 3.2 Gen 2 Type-A ports (red) on the back panel |
| Video Ports | 2 x Thunderbolt™ 4 connectors (USB Type-C® ports, with USB 3.2 Gen 2 support) |
| Audio Chipset | ESS ES9280AC DAC chip + 2 ESS ES9080 chips |
| Max Lan Speed | Marvell® AQtion AQC107 10GbE LAN chip (10 Gbps/5 Gbps/2.5 Gbps/1 Gbps/100 Mbps) (LAN1) |
| Audio Channels | High Definition Audio |
| CPU Socket Type | LGA1700 |
| Memory Standard | Support for DDR5 8000(O.C) / 7950(O.C) / 7900(O.C) / 7800(O.C) / 7600(O.C.) / 7400(O.C.) / 7200(O.C.) / 7000(O.C.) / 6800(O.C.) / 6600(O.C.) / 6400(O.C.) / 6200(O.C.) / 6000(O.C.) / 5800(O.C.) / 5600( |
| Pci Express X16 | 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x4 (PCIEX4) 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x1 (PCIEX1) |
| Channel Supported | Dual Channel DDR5 Memory Technology |
| Second Lan Chipset | Intel® 2.5GbE (2.5 Gbps/1 Gbps/100 Mbps) (LAN2) |
| Onboard Video Chipset | Integrated Graphics Processor+Intel® Thunderbolt™ 4 Controller |
| Number Of Memory Slots | 4x DDR5 |
| Maximum Memory Supported | 128 GB |
