Intel Core i5-12600K Processor

The Intel Core i5-12600K is a 12th Generation Alder Lake desktop processor built on Intel’s Intel 7 process node. It uses Intel’s hybrid architecture, combining 6 Performance-cores and 4 Efficient-cores for a total of 10 cores and 16 threads — making it well suited for demanding multitasking, content creation workflows, and gaming workloads that can take advantage of Intel Thread Director. The Performance-cores reach a base clock of 3.70 GHz and can boost up to 4.90 GHz with Intel Turbo Boost Max Technology 3.0, while the Efficient-cores operate at a 2.80 GHz base and up to 3.60 GHz under turbo. The processor supports up to 128 GB of dual-channel memory — either DDR5 at up to 4800 MT/s or DDR4 at up to 3200 MT/s — giving builders flexibility when choosing a compatible LGA1700 platform motherboard. The i5-12600K ships with an unlocked multiplier, enabling overclocking on compatible Z-series motherboards. It carries a Processor Base Power of 125 W and a Maximum Turbo Power of 150 W, with a TJUNCTION ceiling of 100°C. Note that no CPU cooler is included in the box. Onboard graphics are handled by Intel UHD Graphics 770, featuring 32 Execution Units, a base frequency of 300 MHz, and a maximum dynamic frequency of 1.45 GHz. Display output supports HDMI 2.1 (up to 4K 60Hz), DisplayPort 1.4a (up to 8K 60Hz), and eDP 1.4b, with up to four displays simultaneously. The platform offers up to 20 PCIe lanes with support for PCIe 5.0 and 4.0 configurations, connected via a DMI 4.0 x8 interface. Advanced features include Intel Deep Learning Boost, Intel Gaussian and Neural Accelerator 3.0, AES-NI hardware encryption, and comprehensive virtualisation support (VT-x, VT-d, EPT). Key Verified Specifications: – Socket: FCLGA1700 – Cores / Threads: 10 (6P + 4E) / 16 – P-core Base / Turbo: 3.70 GHz / 4.90 GHz – E-core Base / Turbo: 2.80 GHz / 3.60 GHz – L2 Cache: 9.5 MB | Smart Cache: 20 MB – TDP (Base / Turbo): 125 W / 150 W – Memory: DDR5-4800 or DDR4-3200, dual-channel, max 128 GB – Max Memory Bandwidth: 76.8 GB/s – PCIe: 5.0 + 4.0, up to 20 lanes – iGPU: Intel UHD Graphics 770, 32 EU, up to 1.45 GHz – Lithography: Intel 7 – Warranty: 3 Years
