INTEL Core i7 10700K 10th Generation Processor ( 5.1 GHz / 8 Cores / 16 Threads )
MPN INTEL-11700KA · Brand Intel
Features of INTEL Core i7 10700K 10th Generation Processor The INTEL Core i7 10700 processor INTEL Core i7 10700K is a desktop processor with 8 cores, launched in April 2020. It is part of the Core i7 lineup, using the Comet Lake architecture with Socket 1200. Thanks to Intel Hyper-Threading the core-count is effectively doubled, to 16 threads. Core i7-10700K has 16 MB of L3 cache and operates at 3.8 GHz by default, but can boost up to 5.1 GHz, depending on the workload. Intel is building the Co
Inclusive of GST · GST invoice available
Overview
Features of INTEL Core i7 10700K 10th Generation Processor
The INTEL Core i7 10700 processor INTEL Core i7 10700K is a desktop processor with 8 cores, launched in April 2020. It is part of the Core i7 lineup, using the Comet Lake architecture with Socket 1200. Thanks to Intel Hyper-Threading the core-count is effectively doubled, to 16 threads. Core i7-10700K has 16 MB of L3 cache and operates at 3.8 GHz by default, but can boost up to 5.1 GHz, depending on the workload.
Intel is building the Core i7-10700K on a 14 nm production process, the transistor count is unknown. You may freely adjust the unlocked multiplier on Core i7-10700K, which simplifies overclocking greatly, as you can easily dial in any overclocking frequency.
With a TDP of 125 W, the Core i7-10700K consumes a lot of power, so good cooling is definitely needed. Intel's processor supports DDR4 memory with a dual-channel interface. The highest officially supported memory speed is 2933 MT/s, but with overclocking (and the right memory modules) you can go even higher.
For communication with other components in the system, Core i7-10700K uses a PCI-Express Gen 3 connection. This processor features the UHD Graphics 630 integrated graphics solution.
Hardware virtualization is available on the Core i7-10700K, which greatly improves virtual machine performance. Additionally, IOMMU virtualization (PCI passthrough) is supported, so that guest virtual machines may directly use host hardware.
Programs using Advanced Vector Extensions (AVX) will run on this processor, boosting performance for calculation-heavy applications. Besides AVX, Intel is including the newer AVX2 standard, too, but not AVX-512.
The Intel core i7 10th Gen processor is among the best processors for those who want functional performance for the intel i7 processor price.
- 8 Core & 16 Threads
- 3.8 GHz Clock Speed, 5.1 GHz Maximum Turbo Frequency
- Compatible with Intel 400 series chipset based motherboards
- Intel UHD Graphics 630
- Intel Turbo Boost Max Technology 3.0 Support
- Intel Optane Memory Support
- No Thermal Solution Included
- Avenger Limited Edition Box, Avenger Game Not Included
- Compatible with Intel 500 Series Chipset Based Motherboards
Specifications of INTEL Core i7 10700K 10th Generation Processor
| Product Collection | 10th Generation Intel® Core™ i7 Processors |
| Code Name | Products formerly Comet Lake |
| Vertical Segment | Desktop |
| Processor Number | i7-10700K |
| Lithography | 14 nm |
| Use Conditions | PC/Client/Tablet |
| Performance Specifications | |
| Cores | 8 |
| Threads | 16 |
| Processor Base Frequency | 3.80 GHz |
| Max Turbo Frequency | 5.10 GHz |
| Cache | 16 MB Intel® Smart Cache |
| Bus Speed | 8 GT/s |
| Intel® Turbo Boost Max Technology 3.0 Frequency | 5.10 GHz |
| Intel® Turbo Boost Technology 2.0 Frequency | 5.00 GHz |
| TDP | 125 W |
| Configurable TDP-down Frequency | 3.50 GHz |
| Configurable TDP-down/td> | 95 W |
| Supplemental Information | |
| Embedded Options Available | No |
| Memory Specifications | |
| Max Memory Size (dependent on memory type) | 128 GB |
| Memory Types | DDR4-2933 |
| Max Memory Channels | 2 |
| Max Memory Bandwidth | 45.8 GB/s |
| ECC Memory Supported | No |
| Processor Graphics | |
| Processor Graphics | Intel® UHD Graphics 630 |
| Graphics Base Frequency | 350 MHz |
| Graphics Max Dynamic Frequency | 1.20 GHz |
| Graphics Video Max Memory | 64 GB |
| 4K Support | Yes, at 60Hz |
| Max Resolution (HDMI 1.4) | 4096x2160@30Hz |
| Max Resolution (DP) | 4096x2304@60Hz |
| Max Resolution (eDP - Integrated Flat Panel) | 4096x2304@60Hz |
| DirectX Support | 12 |
| OpenGL Support | 4.5 |
| Intel® Quick Sync Video | Yes |
| Intel® InTru™ 3D Technology | Yes |
| Intel® Clear Video HD Technology | Yes |
| Intel® Clear Video Technology | Yes |
| Displays Supported | 3 |
| Device ID | 0x9BC5 |
| Expansion Options | |
| Scalability | 1S Only |
| PCI Express Revision | 3 |
| PCI Express Configurations | Up to 1x16, 2x8, 1x8+2x4 |
| Max PCI Express Lanes | 16 |
| Advanced Technologies | |
| Intel® Optane™ Memory Supported | Yes |
| Intel® Thermal Velocity Boost | No |
| Intel® Turbo Boost Max Technology 3.0 | Yes |
| Intel® Turbo Boost Technology | 2 |
| Intel® vPro™ Platform Eligibility | Yes |
| Intel® Hyper-Threading Technology | Yes |
| Intel® Virtualization Technology (VT-x) | Yes |
| Intel® Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® VT-x with Extended Page Tables (EPT) | Yes |
| Intel® Transactional Synchronization Extensions | No |
| Intel® 64 | Yes |
| Instruction Set | 64-bit |
| Instruction Set Extensions | Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2 |
| Idle States | Yes |
| Enhanced Intel SpeedStep® Technology | Yes |
| Thermal Monitoring Technologies | Yes |
| Intel® Identity Protection Technology | Yes |
| Intel® Stable Image Platform Program (SIPP) | Yes |
| Security & Reliability | |
| Intel® AES New Instructions | Yes |
| Secure Key | Yes |
| Intel® Software Guard Extensions (Intel® SGX) | Yes with Intel® ME |
| Intel® OS Guard | Yes |
| Intel® Trusted Execution Technology | Yes |
| Execute Disable Bit | Yes |
| Intel® Boot Guard | Yes |
| Package Specifications | |
| Sockets Supported | FCLGA1200 |
| Max CPU Configuration | 1 |
| Thermal Solution Specification | PCG 2015D |
| TJUNCTION | 100°C |
| Package Size | 37.5mm x 37.5mm |
| Warranty | 3 Years |
| Note | ***Features, Price and Specifications are subject to change without notice. |
Datasheet
| Bus Speed | 8 GT/s |
|---|---|
| Code Name | Products formerly Comet Lake |
| Device Id | 0x9BC5 |
| Tjunction | 100°C |
| 4K Support | Yes, at 60Hz |
| Intel® 64 | Yes |
| Secure Key | Yes |
| Idle States | Yes |
| Lithography | 14 nm |
| Scalability | 1S Only |
| Memory Types | DDR4-2933 |
| Package Size | 37.5mm x 37.5mm |
| Opengl Support | 4.5 |
| Use Conditions | PC/Client/Tablet |
| Directx Support | 12 |
| Instruction Set | 64-bit |
| Intel® Os Guard | Yes |
| Processor Number | i7-10700K |
| Vertical Segment | Desktop |
| Sockets Supported | FCLGA1200 |
| Displays Supported | 3 |
| Intel® Boot Guard | Yes |
| Processor Graphics | Intel® UHD Graphics 630 |
| Product Collection | 10th Generation Intel® Core™ i7 Processors |
| Execute Disable Bit | Yes |
| Max Memory Channels | 2 |
| Max Resolution (Dp) | 4096×2304@60Hz |
| Max Turbo Frequency | 5.10 GHz |
| Ecc Memory Supported | No |
| Max Memory Bandwidth | 45.8 GB/s |
| Pci Express Revision | 3 |
| Max Cpu Configuration | 1 |
| Max Pci Express Lanes | 16 |
| Graphics Base Frequency | 350 MHz |
| Intel® Quick Sync Video | Yes |
| Processor Base Frequency | 3.80 GHz |
| Configurable Tdp-Down/Td> | 95 W |
| Graphics Video Max Memory | 64 GB |
| Max Resolution (Hdmi 1.4) | 4096×2160@30Hz |
| Embedded Options Available | No |
| Instruction Set Extensions | Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2 |
| Pci Express Configurations | Up to 1×16, 2×8, 1×8+2×4 |
| Intel® Aes New Instructions | Yes |
| Graphics Max Dynamic Frequency | 1.20 GHz |
| Intel® Clear Video Technology | Yes |
| Intel® Intru™ 3D Technology | Yes |
| Intel® Thermal Velocity Boost | No |
| Intel® Turbo Boost Technology | 2 |
| Thermal Solution Specification | PCG 2015D |
| Configurable Tdp-Down Frequency | 3.50 GHz |
| Thermal Monitoring Technologies | Yes |
| Intel® Clear Video Hd Technology | Yes |
| Intel® Hyper-Threading Technology | Yes |
| Intel® Optane™ Memory Supported | Yes |
| Intel® Trusted Execution Technology | Yes |
| Intel® Vpro™ Platform Eligibility | Yes |
| Enhanced Intel Speedstep® Technology | Yes |
| Intel® Identity Protection Technology | Yes |
| Intel® Turbo Boost Max Technology 3.0 | Yes |
| Intel® Virtualization Technology (Vt-X) | Yes |
| Max Memory Size (Dependent On Memory Type) | 128 GB |
| Intel® Stable Image Platform Program (Sipp) | Yes |
| Intel® Turbo Boost Technology 2.0 Frequency | 5.00 GHz |
| Intel® Vt-X With Extended Page Tables (Ept) | Yes |
| Max Resolution (Edp - Integrated Flat Panel) | 4096×2304@60Hz |
| Intel® Software Guard Extensions (Intel® Sgx) | Yes with Intel® ME |
| Intel® Transactional Synchronization Extensions | No |
| Intel® Turbo Boost Max Technology 3.0 Frequency | 5.10 GHz |
| Intel® Virtualization Technology For Directed I/O (Vt-D) | Yes |
| Warranty | 3 Years |
| Cores | 8 |
| Threads | 16 |
| TDP | 125 W |
| Cache | 16 MB Intel® Smart Cache |
