INTEL Core Ultra 7 265K Processor ( 5.5 GHz / 20 Cores / 20 Threads )

The Intel Core Ultra 7 265K is a high-performance desktop processor belonging to Intel’s Core Ultra Processors (Series 2), codenamed Arrow Lake. It represents a significant architectural shift for Intel’s desktop lineup: rather than a traditional monolithic die, the 265K is assembled from four distinct silicon tiles interconnected via Intel’s Foveros packaging technology on an interposer substrate. This multi-tile design enables tighter integration and higher inter-tile bandwidth compared with conventional approaches. The processor features a heterogeneous core configuration of 8 Performance-cores and 12 Efficient-cores, delivering a total of 20 cores and 20 threads. Notably, Arrow Lake does away with Hyper-Threading on Performance-cores, a deliberate architectural decision that reduces security exposure and eliminates die area previously dedicated to the feature. The Efficient-cores have been substantially revised for this generation and now have access to the shared L3 cache pool. On the frequency side, the 265K reaches a maximum turbo frequency of 5.5 GHz (also the Intel Turbo Boost Max Technology 3.0 frequency), with Performance-core base at 3.9 GHz, P-core max turbo at 5.4 GHz, E-core base at 3.3 GHz, and E-core max turbo at 4.6 GHz. The processor is fabbed on TSMC’s N3B process node. Processor Base Power is 125 W with a Maximum Turbo Power of 250 W. The 265K integrates a dedicated NPU called Intel AI Boost, rated at 13 TOPS (Int8), with the full system delivering an overall peak of 25 TOPS. The NPU supports Windows Studio Effects, Intel OpenVINO, WindowsML, DirectML, ONNX Runtime, and WebNN frameworks, making it a capable platform for device AI inference workloads. Memory support extends to DDR5 at up to 6,400 MT/s across two channels, with a maximum addressable memory of 192 GB. Connectivity is provided through PCIe 5.0 and 4.0 lanes (up to 24 total), DMI 4 with 8 lanes, and Intel Thunderbolt 4. The processor uses the FCLGA1851 socket and operates up to a maximum temperature of 105 °C. Security features include Intel Control-Flow Enforcement Technology, AES-NI, Trusted Execution Technology, Boot Guard, OS Guard, VT-x, VT-d, and Execute Disable Bit. The product carries a 3-year warranty. Verified Specifications: – Product Code: BX80768265K – Architecture: Arrow Lake (Series 2), multi-tile Foveros – Total Cores: 20 (8 P-cores + 12 E-cores) | Total Threads: 20 – Max Turbo Frequency: 5.5 GHz | P-core Base: 3.9 GHz | E-core Base: 3.3 GHz – L3 Cache (Intel Smart Cache): 30 MB | Total L2 Cache: 36 MB – Process Node: TSMC N3B – TDP (Base Power): 125 W | Max Turbo Power: 250 W – NPU: Intel AI Boost — 13 TOPS (Int8) | System Peak TOPS: 25 – Memory: DDR5 up to 6,400 MT/s, 2-channel, max 192 GB – PCIe: 5.0 and 4.0, up to 24 lanes – Socket: FCLGA1851 | Max Operating Temp: 105 °C – Warranty: 3 Years
