MSI MAG A500N-H 500W Non-Modular Power Supply with Active PFC
MPN MAG-A500N-H · Brand MSI
The MSI MAG A500N-H delivers 500 W of stable power through a single-rail design with Active PFC, a quiet 120 mm hydraulic bearing fan, and multi-layer protection including OVP, UVP, OPP, and SCP — backed by a 5-year warranty
Inclusive of GST · GST invoice available
Overview
The MSI MAG A500N-H is a 500-watt non-modular power supply designed for budget-conscious desktop PC builders who need reliable, stable power delivery without unnecessary complexity. Built around a single-rail architecture, it delivers the full 500 W capacity through one consolidated 12 V rail, simplifying compatibility assessment for mainstream CPUs and entry-level discrete graphics cards. At the core of the MAG A500N-H is an Active Power Factor Correction (Active PFC) circuit that stabilises input power drawn from the wall, reduces reactive power waste, and helps protect connected components from voltage irregularities. The unit accepts a wide input voltage range of 200–240 V AC at 50–60 Hz, making it suitable for the Indian mains standard. Thermal management is handled by a 120 mm fan fitted with a hydraulic bearing. Hydraulic bearings offer lower operational noise compared to sleeve bearings and provide a longer service lifespan under continuous use, keeping the PSU running quietly even during sustained loads. Protection circuitry includes Over Voltage Protection (OVP), Under Voltage Protection (UVP), Over Power Protection (OPP), and Short Circuit Protection (SCP), providing a safety net for both the power supply itself and the components it powers. The non-modular cable design means all cables are permanently attached, which is standard at this price point and ensures no loose connector risks during installation. MSI backs the MAG A500N-H with a 5-year warranty, offering meaningful peace of mind for a component that sits at the foundation of any PC build. --- Verified Specifications --- Form Factor: ATX Non-Modular Rated Output Power: 500 W Input Voltage: 200–240 V AC Input Frequency: 50–60 Hz PFC Type: Active PFC Fan Size: 120 mm Fan Bearing: Hydraulic Bearing Rail Design: Single Rail ATX Connector: 1 × 24-pin EPS Connector: 2 × (4+4)-pin PCIe Connector: 1 × (6+2)-pin SATA Connector: 3 × 15-pin MOLEX / Peripheral: 2 × 4-pin FDD Connector: 1 × 4-pin Protection: OVP, UVP, OPP, SCP Dimensions (D × W × H): 140 mm × 150 mm × 86 mm Warranty: 5 Years
Datasheet
| Warranty | 5 Years |
|---|---|
| Modular | NON MODULAR |
| Note*** | Features, Price and Specifications are subject to change without notice. Images use for Representation Purpose Only |
| Wattage | 500 Watt |
| Sata Connector | 3 |
| Peripheral (4-Pin) | 2 |
| PCIE Connector (6+2) | 1 |
