MSI Pro Z890-P WiFi 6E ATX Motherboard for Intel Core Ultra Series 2 (LGA 1851)

The MSI Pro Z890-P WiFi 6E is an ATX form-factor motherboard built on the Intel Z890 chipset, designed specifically for Intel Core Ultra Series 2 processors using the LGA 1851 socket. It brings together a robust power delivery system, next-generation connectivity, and thoughtful ergonomic features that make it a capable platform for content creators, power users, and PC enthusiasts alike. At the heart of its power delivery is a 14+1+1+1 Duet Rail Power System featuring 55A DrMOS power stages, supported by dual 8-pin CPU power connectors. This configuration is designed to handle sustained loads from high-end Intel Core Ultra processors without thermal throttling. The 6-layer PCB uses 2 oz thickened copper traces and specialized PCB fabric for improved signal integrity and current capacity. Memory support extends to DDR5 in dual-channel configuration, with speeds reaching up to 9200 MT/s in overclocked mode. The board supports Intel XMP 3.0, Intel POR speeds, JEDEC specifications, and CUDIMMs, with a maximum capacity of 256 GB across its DIMM slots. Note that DIMM slots use single-sided latches. Storage and expansion are well-addressed: the primary PCIe slot (PCI_E1) operates at PCIe 5.0 x16 directly from the CPU, while additional slots run at PCIe 4.0 from the chipset. An onboard M.2 slot supports Lightning Gen 5 x4, covered by the EZ M.2 Shield Frozr II with a 7W/mK thermal pad for sustained SSD performance. Additional M.2 slots with EZ M.2 Shield Frozr II and choke thermal pads round out the storage options. Networking is handled by a 5G LAN port paired with integrated Wi-Fi 6E and Bluetooth 5.3, delivered via an EZ Antenna connector for straightforward installation. The rear I/O panel includes USB 2.0, USB 5Gbps Type-A, USB 10Gbps Type-A, USB 10Gbps Type-C, HDMI, DisplayPort, and a Flash BIOS button. Internal headers include 4× USB 2.0, 4× USB 5Gbps Type-A, and 1× USB 20Gbps Type-C ports, along with 5 system fan headers, 1 CPU fan, 1 combo pump/system fan, 3× ARGB V2 headers, 1× RGB header, and a TPM 2.0 header. User-friendly features include the EZ PCIe Clip II on the primary slot for single-finger GPU removal, a pre-installed I/O shield, onboard POST diagnostic LEDs, and a JAF_1 header for MSI MPG EZ120 ARGB fans. The silver color scheme suits both white and black builds. Key Verified Specifications: - Socket: LGA 1851 - Chipset: Intel Z890 - Form Factor: ATX - Supported CPUs: Intel Core Ultra Series 2 - Memory: DDR5, Dual Channel, up to 256 GB, up to 9200 MT/s (OC), XMP 3.0 - Primary PCIe Slot: PCIe 5.0 x16 (CPU) - M.2: Lightning Gen 5 x4 (and additional PCIe 4.0 slots) - LAN: 5G - Wireless: Wi-Fi 6E, Bluetooth 5.3 - Rear USB: USB 2.0, USB 5Gbps Type-A, USB 10Gbps Type-A, USB 10Gbps Type-C - Video Output: 1× HDMI, 1× DisplayPort - Power Phases: 14+1+1+1 (55A DrMOS) - Warranty: 3 Years
