Noctua NH-D15 G2 LBC Brown 140mm CPU Air Cooler

The Noctua NH-D15 G2 LBC is the second-generation evolution of one of the most respected dual-tower CPU air coolers ever made. The LBC (Low Base Convexity) variant is specifically engineered for CPU platforms where the contact surface has a lower degree of flatness, ensuring optimal thermal interface contact and the best possible heat transfer between the CPU lid and the heatsink base. At the heart of the NH-D15 G2 LBC are eight copper heatpipes — two more than the original NH-D15 — that dramatically increase thermal capacity under extreme heat loads of 250W and beyond. The asymmetrical, optimised fin-stacks feature a tighter 1.6mm fin spacing (down from 1.9mm in the original), enabling 26 additional fins and a 20% increase in total fin surface area. The front fin-stack has also been narrowed by 5mm to better balance airflow load across both fans. The result is improved cooling performance packaged in a slightly more compact form factor: 9mm less heatsink depth compared to the original NH-D15, with the same width and total height including fans. Power comes from two next-generation NF-A14x25r G2 PWM fans running in a speed-offset configuration. These 140mm round-frame fans are purpose-built to deliver superior airflow and static pressure with exceptional acoustic efficiency, setting a new reference point for performance-to-noise ratio in their class. Installation is handled by Noctua's SecuFirm2+ mounting system, a Torx-based upgrade to the renowned SecuFirm2 platform. The included screwdriver and improved hardware deliver secure, long-lasting mounting across a wide range of modern sockets. For LGA1700 systems, the included NM-ISW1 shim washers reduce ILM pressure on the CPU, which can yield typical temperature improvements of approximately 2–3°C for low or medium convexity coolers. — Verified Specifications — Fan size: 140mm (dual NF-A14x25r G2 PWM) Heatpipes: 8 Fin spacing: 1.6mm Fin surface area: +20% vs original NH-D15 PWM control: Yes Socket support: AMD AM5, AM4 | Intel LGA1851, LGA1700, LGA1200, LGA1150, LGA1151, LGA1155, LGA1156 Compatible CPUs: Intel Core i3/i5/i7/i9, Core Ultra 5/7/9; AMD Ryzen 3/5/7/9 Base variant: LBC (Low Base Convexity) Warranty: 6 years Colour: Brown (Noctua signature) Includes: NM-ISW1 shim washers for LGA1700, SecuFirm2+ Torx screwdriver
