Noctua NH-D15S Asymmetric Single-Fan Dual-Tower CPU Air Cooler

The Noctua NH-D15S is an asymmetric, single-fan variant of Noctua's dual-tower flagship heatsink line, engineered specifically to balance top-tier thermal performance with real-world system compatibility. Unlike symmetrical dual-tower designs, the NH-D15S offsets its fin stack toward the upper edge of the motherboard when installed in standard orientation. This asymmetric layout allows it to clear the top PCIe x16 slot on most µATX and ATX motherboards — a meaningful advantage for builders who run a discrete GPU alongside a high-performance CPU. The recessed lower fins provide 66 mm of clearance for tall memory modules, ensuring the cooler works with most high-end RAM heatsinks on both Intel and AMD platforms without requiring fan repositioning. A single Noctua NF-A15 PWM fan is included in the box, and the cooler ships with extra fan clips so users can add a second 140 mm round-frame fan (120 mm mounting hole pattern) or a standard 120 mm fan at a later date — giving flexibility between compatibility and maximum cooling output. The included NF-A15 fan features Noctua's SSO2 self-stabilising oil-pressure bearing and aerodynamic Flow Acceleration Channels. It spins up to 1500 RPM and delivers up to 140.2 m³/h of airflow at a maximum noise level of 24.6 dB(A). Attaching the supplied NA-RC7 Low-Noise Adaptor drops the fan ceiling to 1200 RPM, reducing airflow to 115.5 m³/h and noise to 19.2 dB(A) for quieter builds. PWM control allows the motherboard to modulate speed automatically, down to a minimum of 300 RPM at 20% PWM duty cycle. Mounting is handled by Noctua's SecuFirm2 system, which supports Intel LGA1851, LGA1700, LGA1200, LGA1156, LGA1155, LGA1151, and LGA1150, as well as AMD AM5 and AM4 sockets. The included NT-H1 thermal compound, a pro-grade TIM, reduces interface resistance between the CPU heat spreader and the copper base. The heatsink body combines a copper base and copper heat-pipes with aluminium cooling fins, nickel-plated for corrosion resistance, and uses soldered fin joints for consistent long-term thermal transfer. The entire package carries a 6-year manufacturer warranty, and the NF-A15 fan is rated to an MTTF of more than 150,000 hours. Verified Specifications: - Dimensions (H × W × D, with fan): 160 mm × 150 mm × 135 mm - Weight (with fan): 1,150 g - Fan model: 1× Noctua NF-A15 PWM (140 mm, SSO2 bearing) - Fan speed range: 300 RPM (min, PWM) – 1,500 RPM (max) - Max airflow: 140.2 m³/h | With LNA: 115.5 m³/h - Max noise: 24.6 dB(A) | With LNA: 19.2 dB(A) - Fan input power: 1.56 W @ 12 V - Socket support: Intel LGA1851/1700/1200/115x; AMD AM5/AM4 - Material: Copper base & heat-pipes, aluminium fins, nickel plating, soldered joints - NSPR: 167 - Warranty: 6 years - In the box: NF-A15 PWM fan, NA-RC7 LNA, fan clips (second fan), NT-H1 thermal compound, SecuFirm2 mounting kit, Noctua metal case badge
