Noctua NH-U14S TR5-SP6 CPU Air Cooler

The Noctua NH-U14S TR5-SP6 is a premium 140mm tower air cooler purpose-built for AMD workstations and servers running Threadripper processors on the sTR5 socket and EPYC processors on the SP6 socket. Designed as an evolution of the established TR4-SP3 platform, it brings the same large heatsink architecture and full-cover copper contact surface to AMD’s latest high-core-count platforms. At the heart of the thermal solution is a copper base measuring 70×56mm — more than double the contact area of a standard desktop cooler — specifically proportioned to match the large integrated heat-spreaders found on sTR5 and SP6 processors. Six heat pipes draw heat efficiently from the base through the aluminium fin stack, which spans a surface area exceeding 6,000 cm². Cooling airflow is handled by two of Noctua’s NF-A15 140mm fans arranged in a push-pull configuration. Both fans support PWM speed control, letting the motherboard ramp RPM up under load and drop back toward near-silence during lighter tasks — an important quality-of-life feature in noise-sensitive production environments such as audio and video editing suites or professional workstations. A splitter cable is included so both fans can be driven from a single fan header. The SecuFirm2 mounting system has been updated to satisfy the higher contact-pressure requirements of the sTR5 and SP6 sockets. Installation follows the same four-screw Allen-key procedure as previous Noctua Threadripper coolers, and the mounting bracket supports 3mm and 6mm offset positions to improve clearance toward the I/O panel or PCIe slots depending on board orientation. Noctua’s NT-H2 pro-grade thermal compound comes pre-applied to the heatsink base, ensuring consistent bond-line thickness straight out of the box — a convenience that benefits both end-users and professional system integrators. Verifiable Specifications: • Socket compatibility: AMD sTR5, AMD SP6 • Fan size: 140mm (NF-A15, quantity 2) • Fan configuration: Push-pull • PWM control: Yes • Heatsink copper contact surface: 70×56mm • Number of heat pipes: 6 • Fin surface area: >6,000 cm² • Thermal compound: Noctua NT-H2 (pre-applied) • Mounting: SecuFirm2 for sTR5/SP6 with 3mm/6mm offset options • Fan MTTF rating: >150,000 hours • Warranty: 6 years (manufacturer) • Compatible CPU families: AMD Ryzen Threadripper (sTR5), AMD EPYC (SP6)
