NOCTUA NH-U14S TR5-SP6 Non-RGB Single Tower CPU Air Cooler

The Noctua NH-U14S TR5-SP6 is a premium 140mm single-tower CPU air cooler purpose-built for AMD Threadripper workstations and Epyc servers using the sTR5 and SP6 sockets. Evolved from Noctua's established TR4-SP3 platform, this revision brings updated SecuFirm2 mounting brackets engineered to satisfy the higher contact-pressure specifications demanded by the sTR5/SP6 socket design, while retaining the same oversized heatsink architecture that has made its predecessor a reference choice in professional environments. At the heart of the cooler sits a copper base measuring 70×56 mm — more than double the contact area of a standard desktop heatsink — matched precisely to the large integrated heat-spreaders found on sTR5 and SP6 processors. Six copper heatpipes transfer heat from the base to an aluminium fin stack offering more than 6,000 cm² of surface area, and the entire assembly is finished with soldered joints and nickel plating for long-term corrosion resistance. Cooling airflow is delivered by two NF-A15 HS-PWM 140mm fans arranged in a push/pull configuration. Running PWM-controlled from a single motherboard header via the included splitter cable, they spin between 300 RPM at light loads and 1,500 RPM at full load, producing a maximum of 140.2 m³/h airflow at a peak noise level of 24.6 dB(A). With the supplied Low-Noise Adaptor (L.N.A.) fitted, airflow reduces to 115.5 m³/h and noise drops to 19.2 dB(A), making this cooler well-suited to acoustically sensitive studios and broadcast environments. The SSO2 self-stabilising oil-pressure bearing underpins an MTTF rating of more than 150,000 hours. Noctua's NT-H2 thermal compound is pre-applied to the heatsink base, ensuring an optimal bond-line thickness out of the box and eliminating one variable during installation. The SecuFirm2 mounting system also permits 3 mm or 6 mm lateral offsets, allowing builders to improve clearance toward the I/O panel or PCIe slots depending on socket orientation. Verified Specifications: - Socket compatibility: AMD sTR5, SP6 - Heatsink height / width / depth (without fan): 165 mm / 150 mm / 52 mm - Overall depth (with fans): 111 mm - Weight (without fan / with fans): 797 g / 1,136 g - Heatpipes: 6 × copper - Fin surface area: >6,000 cm² - Copper base contact area: 70×56 mm - Included fans: 2× Noctua NF-A15 HS-PWM (140mm) - Fan bearing: SSO2 - Max fan speed: 1,500 RPM (±10%); with L.N.A.: 1,200 RPM (±10%) - Min fan speed: 300 RPM at 20% PWM (±20%) - Max airflow: 140.2 m³/h; with L.N.A.: 115.5 m³/h - Max noise: 24.6 dB(A); with L.N.A.: 19.2 dB(A) - Input power: 1.056 W typical / 1.56 W max - Voltage: 12 V - NSPR: 179 - MTTF: >150,000 hours - Warranty: 6 years - Thermal compound: NT-H2 (pre-applied) - Material: Copper base and heatpipes, aluminium fins, soldered joints, nickel plating
