Noctua NH-U9S Chromax Black CPU Air Cooler

The Noctua NH-U9S chromax.black is the all-black edition of Noctua's acclaimed NH-U9S single-tower CPU air cooler, purpose-built for builders who demand quiet, efficient thermal management without sacrificing a clean aesthetic. The cooler's compact 92mm tower heatsink features a fully black-coated aluminium fin stack soldered directly to copper heat-pipes — a construction technique that maintains a superior thermal interface over years of thermal cycling, unlike press-fitted designs where differential expansion between copper and aluminium can cause the joint to loosen over time. Powering airflow is the included NF-A9 PWM chromax.black fan, which leverages Noctua's proprietary AAO (Advanced Acoustic Optimisation) frame and Flow Acceleration Channels. The fan operates between 400 RPM and 2000 RPM under PWM control, delivering up to 78.9 m³/h of airflow at a maximum noise level of just 22.8 dB(A). With the bundled NA-RC7 Low-Noise Adaptor fitted, speed is capped at 1550 RPM and noise drops further to 16.3 dB(A) — making this one of the quieter 92mm coolers available. MTTF is rated above 150,000 hours. The cooler ships with Noctua's NT-H1 professional-grade thermal compound and the SecuFirm2™ multi-socket mounting system. Out of the box it supports Intel LGA1150, LGA1151, LGA1155, LGA1156, LGA1200, LGA2011-0, LGA2011-3, and LGA2066, plus AMD AM2, AM2+, AM3, AM3+, FM1, FM2, FM2+, and AM4. An extra set of fan clips is included for users who wish to add a second NF-A9 fan in a push/pull configuration for additional cooling headroom. With a footprint of just 95 × 95 mm (fan included) and a height of 125 mm, the NH-U9S clears all RAM slots on current Intel platforms and most AMD motherboards, ensuring full memory compatibility regardless of heatspreader height. The all-black colour scheme — fans, anti-vibration pads, clips, and heatsink — integrates seamlessly into dark builds, and optional NA-SAVP5 anti-vibration pads (sold separately) allow colour accent customisation. Verified Specifications: • Fan model: Noctua NF-A9 PWM chromax.black • Fan size: 92 × 92 × 25 mm • Bearing type: SSO2 • Max fan speed: 2000 RPM (±10%); with LNA: 1550 RPM (±10%) • Min fan speed (PWM): 400 RPM (±20%) • Max airflow: 78.9 m³/h; with LNA: 62.6 m³/h • Max acoustic noise: 22.8 dB(A); with LNA: 16.3 dB(A) • Fan input power: 1.2 W; voltage: 12 V • Heatsink height (without fan): 125 mm • Heatsink width (without fan): 95 mm • Heatsink depth (without fan): 68 mm • Weight (without fan): 865 g; with fan: 618 g • Materials: copper base and heat-pipes, aluminium fins, soldered joints, nickel plating • Warranty: 6 years
