Nzxt H5 Flow RGB 2024 Edition E-ATX Mid Tower Case

The NZXT H5 Flow RGB (2024 Edition) is a compact mid-tower chassis engineered for builders who demand strong airflow and GPU cooling without sacrificing a clean aesthetic. Built around a foundation of SGCC steel and dark-tinted tempered glass, it strikes a balance between structural rigidity and visual appeal. Airflow sits at the heart of the H5 Flow RGB’s design. Ultra-fine mesh panels on the front, top, and side allow air to move freely through the case while trapping dust before it reaches your components. The perforated PSU shroud — open on both the side and bottom — channels air from two optional 120mm bottom-mounted fans directly to the GPU, helping keep thermals in check under heavy loads. Out of the box, the case ships with two pre-installed fans: a front-mounted F360 RGB Core (Case Version, 3-pin DC) that delivers 50.1 CFM at up to 1,700 RPM, and a rear-mounted F120Q (Case Version, 3-pin DC) rated at 60.2 CFM at up to 1,350 RPM. Both fans use 3-pin DC connectors. Liquid-cooling builders are equally well served. The front supports radiators up to 360mm, while the top accommodates a 240mm radiator (expandable to 280mm with low-profile memory installed). This makes the H5 Flow RGB a viable home for high-end all-in-one coolers such as the NZXT Kraken 360. Front I/O includes one USB 3.2 Type-A port, one USB 3.2 Type-C port, and a headset audio jack. Seven expansion slots provide ample room for multi-card or large-format GPU configurations, and GPU clearance extends to 410mm. CPU cooler height clearance is up to 170mm, accommodating tall tower air coolers. The case supports E-ATX motherboards up to 277mm wide, as well as ATX, Micro-ATX, and Mini-ITX form factors. Cable management behind the motherboard tray offers up to 28.7mm of routing space, complemented by wide channels, hooks, and straps. Storage options include two 2.5-inch SSD bays and one 3.5-inch HDD bay. Tool-less panel removal on the front, side, and top simplifies access for builds and upgrades. Verified Specifications: • Part Number: CC-H52FB-R1 • Colour: Black • Dimensions (H × W × D): 465 × 225 × 430 mm (18.31 × 8.86 × 16.93 in) • Weight: 7.63 kg / 16.82 lb • Motherboard Support: E-ATX (up to 277mm wide), ATX, Micro-ATX, Mini-ITX • GPU Clearance: Up to 410mm • CPU Cooler Clearance: Up to 170mm • PSU Clearance: Up to 200mm • Front Radiator: Up to 360mm • Top Radiator: Up to 240mm (280mm with low-profile memory) • Fan Support: Front 3×120mm / 2×140mm; Top 2×120mm / 2×140mm; Bottom 2×120mm; Rear 1×120mm • Pre-installed Fans: F360 RGB Core (front, 1,700±200 RPM, 50.1 CFM, 23.3 dBA) + F120Q (rear, 1,350±150 RPM, 60.2 CFM, 24.1 dBA) • Drive Bays: 2× 2.5-inch, 1× 3.5-inch • Expansion Slots: 7 • Front I/O: USB 3.2 Type-A ×1, USB 3.2 Type-C ×1, Headset Audio Jack ×1 • Case Material: SGCC Steel, Dark Tinted Tempered Glass • Warranty: 2 Years
