Nzxt H5 Flow RGB 2024 Edition E-ATX White Mid Tower Case

The NZXT H5 Flow RGB (2024 Edition) is a compact white mid-tower chassis designed around high airflow and strong GPU cooling performance. Built from SGCC steel and finished with dark-tinted tempered glass, it combines structural rigidity with a clean, minimalist aesthetic suited to a wide range of builds. Airflow is at the heart of the H5 Flow RGB's design. Ultra-fine mesh panels on the front, top, and side allow air to move freely through the chassis while filtering dust particles before they reach your components. The perforated PSU shroud — open on both the side and bottom — draws cool air directly from two 120mm bottom-mounted fans (sold separately), routing it toward the GPU for improved thermal headroom under sustained workloads. Out of the box, the case ships with a front-mounted F360 RGB Core fan (Case Version, 3-pin DC) and a rear-mounted F120Q fan (Case Version, 3-pin DC). The F360 RGB Core operates at up to 1,700 ±200 RPM delivering 50.1 CFM of airflow at 23.3 dBA, while the F120Q rear exhaust runs at 1,350 ±150 RPM producing 60.2 CFM at 24.1 dBA. Both are CV (Case Version) units. For enthusiasts planning a liquid-cooled build, the H5 Flow RGB supports a 360mm radiator in the front and up to a 240mm radiator at the top (or 280mm with low-profile memory). This makes it a capable platform for all-in-one or custom liquid cooling configurations without requiring a full tower chassis. Motherboard compatibility spans E-ATX (up to 277mm wide), ATX, Micro-ATX, and Mini-ITX form factors, with seven standard expansion slots. CPU coolers up to 170mm tall and GPUs up to 410mm long are accommodated, while PSUs up to 200mm in length fit within the shrouded bottom compartment. Cable management is handled via wide routing channels, integrated hooks, and velcro straps, with up to 28.7mm of clearance behind the motherboard tray. Front I/O includes one USB 3.2 Type-A port, one USB 3.2 Type-C port, and a combined headset audio jack. Storage is supported via two 2.5-inch SSD bays and one 3.5-inch HDD bay. All front, side, and top panels are tool-less for easy access during builds and maintenance. Key Specifications: - Model / P/N: H5 Flow RGB / CC-H52FW-R1 - Color: White - Dimensions (H × W × D): 465 × 225 × 430 mm (18.31 × 8.86 × 16.93 in) - Weight: 7.63 kg (16.82 lb) - Motherboard Support: E-ATX (up to 277mm wide), ATX, Micro-ATX, Mini-ITX - Material: SGCC Steel, Dark Tinted Tempered Glass - Max CPU Cooler Height: 170 mm | Max GPU Length: 410 mm | Max PSU Length: 200 mm - Fan Support: Front 3×120mm or 2×140mm; Top 2×120mm or 2×140mm; Bottom 2×120mm; Rear 1×120mm - Radiator Support: Front up to 360mm; Top up to 240mm (280mm with low-profile memory) - Pre-installed Fans: 1× F360 RGB Core (front, 3-pin), 1× F120Q (rear, 3-pin) - Drive Bays: 2× 2.5-inch, 1× 3.5-inch - Front I/O: 1× USB 3.2 Type-A, 1× USB 3.2 Type-C, 1× Headset Audio Jack - Expansion Slots: 7 standard - Cable Management: Up to 28.7 mm clearance - Warranty: 2 Years
