NZXT H510 Elite ATX Mid Tower Cabinet (Matte Black)

The NZXT H510 Elite (Model: CA-H510E-B1) is a compact ATX mid-tower PC cabinet finished in matte black and constructed from SGCC steel and tempered glass. Two full-length tempered glass panels — one on the front and one on the side — give the build an unobstructed, showcase-ready aesthetic while the iconic cable management bar keeps wiring neat behind the scenes. Airflow is managed by four included fans: two Aer RGB 2 140mm fans at the front, one Aer F140 at the top, and one Aer F120 at the rear. The front Aer RGB 2 fans spin between 500 and 1,500 RPM, deliver up to 91.19 CFM of airflow, and operate with a noise profile of 22–33 dBA. Each uses a fluid dynamic bearing and connects via a 4-pin PWM header. Dust filters cover all air intakes. The included NZXT Smart Device V2 provides three fan channels (max 10 W per channel) and two HUE 2 RGB lighting channels, each capable of driving up to four HUE 2 LED strips or five Aer RGB 2 fans. A built-in noise detection module is also on board. One integrated RGB LED strip is pre-installed; no additional strips are included. The front I/O panel features a USB 3.1 Gen 2 Type-C connector — compatible with smartphones and high-speed external storage — alongside a USB 3.1 Gen 1 Type-A port and a headset audio jack. The case supports ATX motherboards and offers seven expansion slots. Storage options include up to three 2.5-inch and three 3.5-inch drive positions. A removable radiator mounting bracket at the front supports up to 280mm radiators (2×140mm or 2×120mm with pull configuration); the rear supports a single 120mm radiator. GPU clearance reaches 368.5mm, and the CPU cooler height limit is 165mm. All dimensions are W: 210mm × H: 435mm × D: 428mm (without feet) and W: 210mm × H: 460mm × D: 428mm (with feet). The case carries a 2-year manufacturer warranty. NZXT CAM software is used for fan and lighting control and requires an internal USB 2.0 header, a Windows 10 or later system, and an internet connection. Verified Specifications: • Model: CA-H510E-B1 • Form Factor: ATX Mid Tower • Dimensions: 210 × 435 × 428mm (without feet) • Material: SGCC Steel + Tempered Glass • Motherboard Support: ATX • Fan Support: Front 2×120/140mm, Top 1×120/140mm, Rear 1×120mm • Included Fans: 2× Aer RGB 2 140mm (front), 1× Aer F140 (top), 1× Aer F120 (rear) • Aer RGB 2 140mm: 500–1,500 RPM, 30.39–91.19 CFM, 22–33 dBA, Fluid Dynamic Bearing, 4-pin PWM • Radiator Support: Front 2×140 or 2×120mm; Rear 1×120mm • GPU Clearance: up to 368.5mm • CPU Cooler Clearance: up to 165mm • I/O: 1× USB 3.1 Gen 2 Type-C, 1× USB 3.1 Gen 1 Type-A, 1× Headset Audio Jack • Expansion Slots: 7 • Drive Bays: 2.5″ 2+1, 3.5″ 2+1 • Smart Device V2: 3× fan channels (10 W each), 2× RGB channels • Warranty: 2 Years
