ProLab Design AI360LC 360mm CPU Liquid Cooler
MPN AI360LC · Brand ProLab DESIGN
The ProLab DESIGN AI360LC is a non-RGB 360mm AIO CPU liquid cooler featuring a 2700 RPM pump, 3348 sq-mm cold plate, high-density ~30 FPI radiator, and out-of-the-box support for Intel, AMD, and Threadripper sockets — backed by a 5-year limited warranty
Inclusive of GST · GST invoice available
Overview
The ProLab DESIGN AI360LC is a 360mm all-in-one (AIO) CPU liquid cooler engineered for high-performance desktop and HEDT workstations. At its core is a 2700 RPM pump housed in a compact CPU block that features a large 3348 sq-mm rectangular cold plate, designed to cover the full integrated heat spreader (IHS) of modern high-TDP processors including Intel LGA 17xx/18xx and AMD Threadripper platforms. The radiator ships with three 120mm fans running in a wire-free daisy-chain configuration: all three fans connect together and feed into a single 4-pin PWM header, while the pump block uses a separate 3-pin PWM connector — only two headers are required in total. The fans spin up to 2500 RPM and deliver 73.5 CFM of airflow at 4.5 mmAq of static pressure, making them well-suited for densely built systems where static pressure matters. The radiator itself uses a high fin-per-inch (FPI) design, rated at approximately 30 FPI, compared to roughly 25 FPI on conventional V-fin radiators — a denser fin stack that promotes faster heat dissipation under sustained loads. The cooler carries a fully muted aesthetic: no RGB lighting on any component, with an all-black finish and silver accents. The tubing is braided PTFE construction, described by ProLab as kink-free and heat-resistant for longevity under prolonged workloads. Socket compatibility spans the full range of Intel, AMD, and HEDT platforms, including the latest consumer sockets. Threadripper TR4, SP3, sTRX4, and sWRX8 support is included in the box, which is uncommon at this price point. ProLab DESIGN backs the AI360LC with a 5-year limited warranty that includes doorstep pickup and drop service through their website. Verified Specifications: • Radiator size: 360mm (3 × 120mm fans) • Fan speed: up to 2500 RPM • Fan airflow: 73.5 CFM • Fan static pressure: 4.5 mmAq • Pump speed: 2700 RPM • Cold plate area: 3348 sq-mm (rectangular) • Radiator FPI: ~30 • PWM connections required: 2 (1 × 4-pin fan, 1 × 3-pin pump) • RGB: None • Tubing: Braided PTFE • Intel socket support: LGA1851, LGA1700, LGA1200, LGA1155, LGA1150, LGA1151, LGA1366 • AMD socket support: AM5, AM4, AM3+, AM3, AM2+, AM2, AM1, FM2+, FM2, FM1 • Threadripper socket support: TR4, SP3, sTRX4, sWRX8 • Warranty: 5 Years Limited (with doorstep pickup) • Price (at time of listing): ₹6,650 INR
Datasheet
| Warranty | 5 Years |
|---|---|
| Note*** | Features, Price and Specifications are subject to change without notice. Images use for Representation Purpose Only |
| Fan Size | 120 mm |
| Cooling Type | LIQUID AIO COOLER |
| Radiator Size | 360 mm |
| Pwm Controller | YES |
| Socket Support | LGA1851,LGA1700,LGA1200,LGA1155,LGA1150,LGA1151,LGA1366,AM5,AM4,AM3,AM2,AM1,FM2,FM1,TR4,SP3,sTRX4,sWRX8 |
| Supported Cooler CPU Wise | intel i3,intel i5,intel i7,intel i9,Core ultra 5,Core ultra 7,Core ultra 9,AMD Ryzen 3,AMD Ryzen 5,AMD Ryzen 7,AMD Ryzen 9,AMD Threadripper |
