THERMALTAKE Divider 500 ATX Air Mid Tower Cabinet (Black)

The Thermaltake Divider 500 TG Air (model CA-1T4-00M1WN-02) is an ATX mid-tower PC cabinet finished in black, built around a signature symmetrical triangular side-panel design. The chassis ships with two 3mm tempered glass panels and a matching steel panel on opposite sides, all tool-free removable, letting builders swap panes to vary the look and airflow strategy without additional hardware. Airflow is a clear focus. Two large mesh panels — one at the front and one at the top — channel air directly over critical components. Two 120 x 120 x 25 mm fans (1,200 RPM, 22 dBA each) come pre-installed: one front intake and one rear exhaust. The fan ecosystem scales significantly further: the front can accept up to three 120mm or three 140mm fans; the top accommodates up to two 140mm fans; the right motherboard side supports up to two 120mm fans; the rear takes one 120mm unit. For liquid-cooling setups, the front supports radiators up to 360mm, the top handles up to 280mm, the motherboard side fits up to a 240mm (vertical GPU recommended), and the rear supports a 120mm radiator. Seven patented rotatable PCI-E expansion slots allow GPU installation both horizontally and vertically, supported further by a built-in riser GPU bracket that reduces mechanical stress on the PCI-E slot. A PSU shroud conceals cables and maintains clean internal aesthetics. The case accommodates Mini-ITX, Micro-ATX, and full ATX motherboards. CPU cooler clearance reaches 170mm with two tempered glass panels fitted, or 155mm in the default mixed TG-and-steel configuration. GPU length clearance is 390mm without a radiator (360mm with one). PSU clearance is 220mm without an HDD cage and 180mm with it. Storage flexibility comes via two 3.5-inch and five 2.5-inch drive bays, expandable to seven 2.5-inch SSDs by removing the HDD cage. The top I/O panel includes one USB 3.2 Gen 2 Type-C port, two USB 3.0 ports, and HD Audio. Removable dust filters cover the front, top, base, and inner right side. Verified Specifications: – P/N: CA-1T4-00M1WN-02 – Dimensions (H x W x D): 530 x 230 x 466 mm (20.9 x 9.1 x 18.3 in) – Net Weight: 10.29 kg / 22.69 lbs – Material: SPCC steel; Side Panels: 3mm Tempered Glass x 2 – Motherboard Support: Mini-ITX, Micro-ATX, ATX – Expansion Slots: 7 (rotatable patented design) – Pre-installed Fans: 2 x 120mm (1,200 RPM, 22 dBA) – Max Radiator Front: 360mm; Top: 280mm; MB Side: 240mm; Rear: 120mm – Drive Bays: 2 x 3.5-inch + 5 x 2.5-inch (or 7 x 2.5-inch SSD) – I/O: USB 3.2 Gen 2 Type-C x 1, USB 3.0 x 2, HD Audio x 1 – PSU: Standard PS2 ATX (not included) – Color: Black
