Thermaltake Toughliquid Ultra 240 CPU Liquid Cooler
MPN CL-W322-PL12GM-B · Brand THERMALTAKE
The Thermaltake Toughliquid Ultra 240 AIO cooler features a 2.1" rotational IPS LCD display, dual TOUGHFAN 12 Turbo fans (up to 2500 RPM), and broad Intel/AMD socket compatibility including LGA1700 and AM5
Inclusive of GST · GST invoice available
Overview
The Thermaltake Toughliquid Ultra 240 is a 240 mm all-in-one liquid CPU cooler built around a standout 2.1-inch rotational TFT-LCD IPS display that shows real-time system information and can cycle through user-uploaded JPG or GIF files at 480×480 resolution. Managed through the TT RGB Plus 2.0 software — the only compatible software for this series — the display connects via a Micro USB to USB 9-pin header and supports Windows 7, 8, 8.1, and 10 operating systems. Cooling performance is handled by two TOUGHFAN 12 Turbo fans, each measuring 120×120×25 mm. Running on PWM control across a 500–2500 RPM range, each fan delivers up to 72.69 CFM of airflow and 3.78 mm-H₂O static pressure, while keeping noise to a rated 28.1 dB-A. The aluminum radiator measures 273×120×27 mm and connects to the system via 400 mm rubber tubing. The low-evaporation tube design is intended to minimise coolant loss over time, removing the need for periodic refilling. Heat transfer from the processor is managed through a copper cold-plate water block. The pump operates at 3200 RPM, rated at 12 V / 0.38 A with a power draw of 4.56 W, providing continuous water circulation to keep the cold plate cool under sustained load. The display module draws 5 V and consumes up to 11.5 W independently. Socket compatibility spans a wide range of Intel and AMD platforms: Intel LGA 2066, 2011-3, 2011, 1700, 1200, 1156, 1155, 1151, and 1150; AMD AM5, AM4, AM3+, AM3, AM2+, AM2, FM2, and FM1. The cooler carries a 2-year manufacturer warranty. — Verified Specifications — Model / P/N: CL-W322-PL12GM-B Radiator: 273×120×27 mm, Aluminum, 240 mm class Fans: 2× TOUGHFAN 12 Turbo, 120×120×25 mm, PWM 500–2500 RPM Max Airflow (per fan): 72.69 CFM Max Pressure (per fan): 3.78 mm-H₂O Noise Level: 28.1 dB-A (per fan) Fan Power: 2.76 W per fan, 12 V / 0.23 A Water Block: Copper Pump Speed: 3200 RPM, 12 V / 0.38 A, 4.56 W Tube Length: 400 mm, Rubber LCD: 2.1" TFT-LCD IPS, 480×480 px, 5 V / 11.5 W LCD Interface: Micro USB to USB (9-pin) Warranty: 2 Years
Datasheet
| Warranty | 2 Years |
|---|---|
| Fan | Dimension : 120 x 120 x 25 mm Speed : PWM 500~2500 R.P.M (2510-4PIN) Noise Level : 28.1 dB-A Power Input : 2.76 W (one fan) Rated Voltage : 12 V Rated Current : 0.23A (one fan) Max. Air Flow : 72.69 CFM (one fan) Max. Pressure : 3.78 mm-H2O (one fan) |
| P/N | CL-W322-PL12GM-B |
| Pump | Motor Speed : 3200 RPM Rated Voltage : 12V Rated Current : 0.38A Power Input : 4.56W |
| Tube | Length : 400 mm Material : Rubber |
| Fan Size | 120 mm |
| Radiator | Dimension : 273 x 120 x 27 mm Material : Aluminum |
| CPU Display | Rated Voltage : 5 V Power Input : 11.5 W Display Type : 2.1” TFT-LCD (IPS) Display Resolution : 480×480 (RGB) px |
| Water Block | Material : Copper |
| Cooling Type | LIQUID AIO COOLER |
| Compatibility | Intel : LGA 2066/2011-3/2011/1700/1200/1156/1155/1151/1150 AMD : AM5/AM4/AM3+/AM3/AM2+/AM2/FM2/FM1 |
| Radiator Size | 240 mm |
| Socket Support | LGA1700,LGA1200,LGA1155,LGA1156,LGA1151,AM5,AM4 |
| Display Support | Interface : Micro USB to USB (9PIN) System Compatibility : Windows 7 / 8 / 8.1 / 10 |
